WESPC Water Temperature Sensor W85720580 For Perkins 403A-11 403A-15 403D-11 Engine
WESPC Water Temperature Sensor W85720580 For Perkins 403A-11 403A-15 403D-11 Engine
WESPC Water Temperature Sensor W85720580 For Perkins 403A-11 403A-15 403D-11 Engine
WESPC Water Temperature Sensor W85720580 For Perkins 403A-11 403A-15 403D-11 Engine
WESPC Water Temperature Sensor W85720580 For Perkins 403A-11 403A-15 403D-11 Engine
WESPC Water Temperature Sensor W85720580 For Perkins 403A-11 403A-15 403D-11 Engine
WESPC Water Temperature Sensor W85720580 For Perkins 403A-11 403A-15 403D-11 Engine
WESPC Water Temperature Sensor W85720580 For Perkins 403A-11 403A-15 403D-11 Engine
Specifications
Brand Name :
WESPC
Model Number :
W85720580
Certification :
ISO9001
Place of Origin :
China
MOQ :
10
Price :
$13-$15(1 Piece)
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
In stock
Delivery Time :
5-10 work days
Packaging Details :
carton
Product Name :
Water Temperature Sensor W85720580
Condition :
100%new
Quality Class :
High-Quality
Stock :
Yes
Warranty :
1year
Packaging :
Carton
Description

WESPC Water Temperature Sensor W85720580 For Perkins 403A-11 403A-15 403D-11 Engine


Brand Name WESPC
Place of Origin China

Part Number

 W85720580
After-sales Service Provided Video Technical Support, Online Support
Marketing Type Ordinary Product
Certificate ISO9001
Warranty 1 Year
Stock Yes


Application:

Water Temperature Sensor W85720580 is engineered for the latest Perkins 400 Series—403A-11, 403A-15, 403D-11, 403D-15, 403F-11 and 403F-15—as well as the 404A-22 and 404D-22/22TA turbocharged diesels, all of which descend directly from the T4.236 and AT4.236 4.0 L architecture. These engines continue to power agricultural tractors, combine harvesters, generator sets and industrial machinery worldwide, where accurate coolant-temperature feedback is essential for emissions compliance and engine protection.

Technical specifications:

Thread M14 × 1.5, hex 19 mm, probe length 42 mm. The sensing element is a negative-temperature-coefficient (NTC) thermistor calibrated 2.5 kΩ ±2 % at 25 °C, falling to 120 Ω ±3 % at 100 °C, delivering a seamless 0–5 V ratiometric signal to the engine control module.


Material & performance features:

The probe shell is precision-machined from lead-free brass and nickel-plated to resist corrosion from glycol-based coolants. The sensing tip is over-moulded in glass-filled PPS, then potted in high-temperature epoxy for complete immunity to vibration, moisture and electromagnetic interference.


Interchange part numbers:

W85720580, 341-3600, 3413600, 2848A129, 2848A127.
