Specifications
Certification :
CE/RoHS/FCC/LVD/EMC
Place of Origin :
China
Sample Service :
Samples offered for quality evaluation
Production Capacity :
Full production lines, support large project orders
Delivery Time :
3-7 working days
MOQ :
1
Warranty Period :
3‑5 years warranty under normal use
Brand Name :
Crane
Supply Ability :
5000 Pieces Per Month
Customization Service :
OEM & ODM available, customize power, CCT, angle, color, logo
Manufacturing Experience :
Over 10 years outdoor LED lighting manufacturing
Description
  1. 1. Extruded Aluminum Alloy Housing for Efficient Heat Dissipation
    Built with extruded aluminum alloy shell that possesses outstanding heat conductivity; the optimized structural design achieves great cost performance while ensuring long-term stable heat dissipation to extend LED service life.
  2. 2. Stable SMD LED & Standard Optical Lens for Even Illumination
    Adopts high-stability SMD LED chips as light source, paired with standard professional optical lenses to output smooth, uniform wall washing light, eliminating uneven light spots and dark areas on building walls.
  3. 3. IP65 Weatherproof for General Outdoor Conditions
    IP65 full weatherproof sealing structure, perfectly adaptable to ordinary outdoor environments with frequent rain, dust and temperature fluctuations, reliable for long-term exterior use.
  4. 4. Dual Control Options & Simple Plug-and-Play Setup
    Two flexible control options available: built-in self-programmed internal control with preloaded dynamic light modes, or single-color constant static light. Simple plug-and-play structure enables fast, effortless installation without complex wiring work.
  5. 5. Constant Voltage Energy-Saving Driver, High Cost Efficiency
    Comes with stable constant voltage power supply with low power loss and energy-saving circuit design. It greatly reduces electricity expenditure, a budget-friendly choice for conventional landscape and building facade lighting engineering projects.

Product Specifications

Voltage DC24V / AC220V IP Rating IP65
Power 12W / 144W Housing Material Extruded Aluminum Profile, Grey
Light Color 2000-6500K / RGB / RGBW Cable & Connector PVC/ Rubber Round Cable / 5‑core Connector
Beam Angle 15*18° / 15* 45°/ 10°/ 30°/ 60° Cover Aluminum Cover
LED Brand & Quantity 24/36pcs OSRAM LEDs Luminous Efficacy 85lm/W
Control Mode ON/OFF / DMX512 CRI Ra80
Segment Control 1‑segment / 4‑segments / 8‑segments per 1M Dimensions L1000*W80*H133
Available Models
Model No. Size Voltage Power Light Source Effect / Control Mode
CXL-DZS72-M1-C1 L1000*W80*H133 DC24V 72W Monochrome Constant On
CXL-DZS72-M5a-C1 L504*W80*H133 DC24V 36W Monochrome Constant On
CXL-DZS72-M3a-C1 L256*W80*H133 DC24V 18W Monochrome Constant On
CXH-DZS72-M1-C1 L1000*W80*H133 AC220V 72W Monochrome Constant On
CXH-DZS72-M5a-C1 L504*W80*H133 AC220V 36W Monochrome Constant On
CXH-DZS72-M3a-C1 L256*W80*H133 AC220V 18W Monochrome Constant On
CXL-DZS60-M1-C1 L1000*W80*H133 DC24V 60W Monochrome Constant On
CXL-DZS60-M5a-C1 L504*W80*H133 DC24V 30W Monochrome Constant On
CXL-DZS60-M3a-C1 L256*W80*H133 DC24V 15W Monochrome Constant On
CXH-DZS60-M1-C1 L1000*W80*H133 AC220V 60W Monochrome Constant On
CXH-DZS60-M5a-C1 L504*W80*H133 AC220V 30W Monochrome Constant On
CXH-DZS60-M3a-C1 L256*W80*H133 AC220V 15W Monochrome Constant On
CXL-DZS48-M1-C1 L1000*W80*H133 DC24V 48W Monochrome Constant On
CXL-DZS48-M5a-C1 L500*W80*H133 DC24V 24W Monochrome Constant On
CXL-DZS48-M3a-C1 L250*W80*H133 DC24V 12W Monochrome Constant On
CXH-DZS48-M1-C1 L1000*W80*H133 AC220V 48W Monochrome Constant On
CXH-DZS48-M5a-C1 L500*W80*H133 AC220V 24W Monochrome Constant On
CXH-DZS48-M3a-C1 L250*W80*H133 AC220V 12W Monochrome Constant On
CXL-DZS72-M1-D3 L1000*W80*H133 DC24V 72*1.5W RGB 3‑in‑1 DMX512
CXL-DZS72-M5a-D3 L504*W80*H133 DC24V 36*1.5W RGB 3‑in‑1 DMX512
CXL-DZS72-M3a-D3 L256*W80*H133 DC24V 18*1.5W RGB 3‑in‑1 DMX512
CXL-DZS72-M1-D4 L1000*W80*H133 DC24V 72*2W RGBW 4‑in‑1 DMX512
CXL-DZS72-M5a-D4 L504*W80*H133 DC24V 36*2W RGBW 4‑in‑1 DMX512
CXL-DZS72-M3a-D4 L256*W80*H133 DC24V 18*2W RGBW 4‑in‑1 DMX512
CXL-DZS60-M1-D3 L1000*W80*H133 DC24V 60*1.5W RGB 3‑in‑1 DMX512
CXL-DZS60-M5a-D3 L504*W80*H133 DC24V 30*1.5W RGB 3‑in‑1 DMX512
CXL-DZS60-M3a-D3 L256*W80*H133 DC24V 15*1.5W RGB 3‑in‑1 DMX512
CXL-DZS60-M1-D4 L1000*W80*H133 DC24V 60*2W RGBW 4‑in‑1 DMX512
CXL-DZS60-M5a-D4 L504*W80*H133 DC24V 30*2W RGBW 4‑in‑1 DMX512
CXL-DZS60-M3a-D4 L256*W80*H133 DC24V 15*2W RGBW 4‑in‑1 DMX512
CXL-DZS48-M1-D3 L1000*W80*H133 DC24V 48*1.5W RGB 3‑in‑1 DMX512
CXL-DZS48-M5a-D3 L500*W80*H133 DC24V 24*1.5W RGB 3‑in‑1 DMX512
CXL-DZS48-M3a-D3 L250*W80*H133 DC24V 12*1.5W RGB 3‑in‑1 DMX512
CXL-DZS48-M1-D4 L1000*W80*H133 DC24V 48*2W RGBW 4‑in‑1 DMX512
CXL-DZS48-M5a-D4 L500*W80*H133 DC24V 24*2W RGBW 4‑in‑1 DMX512
CXL-DZS48-M3a-D4 L250*W80*H133 DC24V 12*2W RGBW 4‑in‑1 DMX512
