Outdoor Waterproof LED Point Source Curtain Wall Light IP67 Rating Intelligent Control
Outdoor Waterproof LED Point Source Curtain Wall Light IP67 Rating Intelligent Control
Outdoor Waterproof LED Point Source Curtain Wall Light IP67 Rating Intelligent Control
Outdoor Waterproof LED Point Source Curtain Wall Light IP67 Rating Intelligent Control
Outdoor Waterproof LED Point Source Curtain Wall Light IP67 Rating Intelligent Control
Outdoor Waterproof LED Point Source Curtain Wall Light IP67 Rating Intelligent Control
Outdoor Waterproof LED Point Source Curtain Wall Light IP67 Rating Intelligent Control
Outdoor Waterproof LED Point Source Curtain Wall Light IP67 Rating Intelligent Control
Outdoor Waterproof LED Point Source Curtain Wall Light IP67 Rating Intelligent Control
Outdoor Waterproof LED Point Source Curtain Wall Light IP67 Rating Intelligent Control
Outdoor Waterproof LED Point Source Curtain Wall Light IP67 Rating Intelligent Control
Outdoor Waterproof LED Point Source Curtain Wall Light IP67 Rating Intelligent Control
Specifications
Certification :
CE/ROHS/EMC/FCC/LVD
Warranty Period :
3‑5 years warranty under normal use
Place of Origin :
China
Design Service :
Offer lighting, optical & structural design for projects
Supply Ability :
500000 Pieces Per Month
Customization Service :
OEM & ODM available, customize power, CCT, angle, color, logo
Delivery Time :
3‑7 working days
Manufacturing Experience :
Over 10 years outdoor LED lighting manufacturing
Brand Name :
CRANE
Production Capacity :
Full production lines, support large project orders
MOQ :
1 Piece
Sample Service :
Samples offered for quality evaluation
Description

✅ High waterproof rating, stable outdoor performance against rain and humidity

✅ Low voltage DC power supply, safe for engineering installation

✅ Support DMX512 / SPI intelligent control, multiple lighting modes

✅ Optional RGB / RGBW full color, rich color presentation

✅ Break-point transmission function, single lamp fault will not affect the whole string

✅ Compact structure, easy mounting, convenient wiring

✅ High light efficiency, low power consumption, long service life

✅ Anti-UV housing, anti-corrosion, suitable for long-term outdoor use

Key attributes

Voltage DC24V
IP Rating IP67
Power

0.9W
Housing Material PVC
Light Color 1800K-6500K / RGB / RGBW
Cable & Connector Rubber Round Cable / SK18 5‑core Solid Pin Connector
Beam Angle 120°
Cover PC
LED Brand & Quantity 3pcs/SMD
Luminous Efficacy 100lm/W
Control Mode ON/OFF / DMX512
CRI Ra90
Segment Control 1‑segment
Dimensions Φ37MM

Product Description

Model No. Size Voltage Power Light Source Effect / Control Mode
CDL-YY3-M1-C1 Φ37MM DC12V 0.9W Single color ON/OFF
CDL-YY3-M1-D3 Φ37MM DC12V 0.9W RGB 3 in 1 DMX512
CDL-YY3-M1-D4 Φ37MM DC12V 0.9W RGBW 4 in 1 DMX512
