IP67 Waterproof LED Flood Light Anti‑glare Shield Aluminum Body RGBW DMX512 Control for Municipal Architectural Lighting
IP67 Waterproof LED Flood Light Anti‑glare Shield Aluminum Body RGBW DMX512 Control for Municipal Architectural Lighting
IP67 Waterproof LED Flood Light Anti‑glare Shield Aluminum Body RGBW DMX512 Control for Municipal Architectural Lighting
IP67 Waterproof LED Flood Light Anti‑glare Shield Aluminum Body RGBW DMX512 Control for Municipal Architectural Lighting
IP67 Waterproof LED Flood Light Anti‑glare Shield Aluminum Body RGBW DMX512 Control for Municipal Architectural Lighting
IP67 Waterproof LED Flood Light Anti‑glare Shield Aluminum Body RGBW DMX512 Control for Municipal Architectural Lighting
IP67 Waterproof LED Flood Light Anti‑glare Shield Aluminum Body RGBW DMX512 Control for Municipal Architectural Lighting
IP67 Waterproof LED Flood Light Anti‑glare Shield Aluminum Body RGBW DMX512 Control for Municipal Architectural Lighting
IP67 Waterproof LED Flood Light Anti‑glare Shield Aluminum Body RGBW DMX512 Control for Municipal Architectural Lighting
IP67 Waterproof LED Flood Light Anti‑glare Shield Aluminum Body RGBW DMX512 Control for Municipal Architectural Lighting
Specifications
Certification :
CE/RoHS/FCC/LVD/EMC
Warranty Period :
3‑5 years warranty under normal use
Supply Ability :
15000 Pieces Per Month
Customization Service :
OEM & ODM available, customize power, CCT, angle, color, logo
Delivery Time :
3‑7 working days
Production Capacity :
Full production lines, support large project orders
Place of Origin :
China
Manufacturing Experience :
Over 10 years outdoor LED lighting manufacturing
Brand Name :
Crane
Design Service :
Offer lighting, optical & structural design for projects
MOQ :
1
Sample Service :
Samples offered for quality evaluation
Description
  • This flood light provides 48W and 96W power versions with unified width & height specifications, sized L250*W200*H240mm and L494*W200*H240mm. It supports DC24V safety low voltage and AC220V mains power, including static monochrome steady lighting and DMX512 programmable dynamic modes, ideal for building facade and plaza landscape projects for convenient batch installation.

    The lamp adopts perforated die-cast aluminum shell with efficient heat dissipation and tight sealing for reliable outdoor waterproof and dustproof performance. Rapid heat discharge prevents brightness drop caused by overheating, while the housing resists UV aging and drastic temperature changes to maintain stable operation amid various global outdoor climates all year round.

    It is equipped with diversified light sources to satisfy different project demands. Monochrome chips deliver soft steady illumination; RGB and RGBW modules achieve rich color performance. Fully compatible with DMX512 control system, it realizes gradient color and flowing light effects for high-end cultural tourism night scene design.

    The adjustable metal bracket enables flexible beam positioning to fit various lighting angles. Modular design simplifies installation and after-sales maintenance to lower overall project costs. We offer stable bulk delivery and flexible OEM & ODM customization services for global landscape contractors and lighting wholesale partners.

  • Product Specifications

  • Voltage DC24V / AC220V
    		IP Rating IP65 / IP66
    Power

    48W / 96W / 192W
    		Housing Material Extruded Aluminum Profile, Grey
    Light Color 2000-6500K / RGB / RGBW
    		Cable & Connector Rubber Round Cable / SK18 5‑core Solid Pin Connector
    Beam Angle 10° / 15° / 20° / 25° / 30° / 45°
    		Cover Silk‑screen Aperture Tempered Glass
    LED Brand & Quantity 48/96pcs OSRAM LEDs
    		Luminous Efficacy 80lm/W
    Control Mode ON/OFF / DMX512
    		CRI Ra80 / Ra90
    Segment Control 1‑segment
    		Dimensions L250*W200*H240MM / L494*W200*H240MM


  • Available Models

    Model No. Size Voltage Power Light Source Effect / Control Mode
    CTL-BYZ48-M1-C1 L250*W200*H240MM DC24V 48W Single Color ON/OFF
    CTH-BYZ48-M1-C1 L250*W200*H240MM AC220V 48W Single Color ON/OFF
    CTL-BYZ48-M1-D3 L250*W200*H240MM DC24V 48*1.5W RGB DMX512
    CTL-BYZ48-M1-D4 L250*W200*H240MM DC24V 48*2W RGBW DMX512
    CTL-BYZ96-M1-C1 L494*W200*H240MM DC24V 96W Single Color ON/OFF
    CTH-BYZ96-M1-C1 L494*W200*H240MM AC220V 96W Single Color ON/OFF
    CTL-BYZ96-M1-D3 L494*W200*H240MM DC24V 96*1.5W RGB DMX512
    CTL-BYZ96-M1-D4 L494*W200*H240MM DC24V 96*2W RGBW DMX512
