Specifications
Brand Name :
SOOME
Model Number :
SMDB-1250
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Price :
Contact
Payment Terms :
L/C, T/T
Supply Ability :
50 Sets/Month
Delivery Time :
5 Days
Packaging Details :
Wooden case or plastic film;LCL or 1*20'Container
Strapper speed :
55 boxes/min
Power :
600W 10A
Belt width :
5-9mm
Belt thickness :
0.5-0.6mm
Glue way :
Heat fusion
Air pressure :
0.4-0.6MPa
Max.strapping size :
W1200*H420
Usage :
Strapping carton box
Description

1250 Type Offline Carton Box Strapping Machine Bundle Corrugated Sheet

Automatic unmanned baler according to the latest development of electronic logic circuit system, can improve the speed and accuracy of the machine. The machine can achieve unattended baling, also can control the whole baling process by single key, simple and easy to use. According to customer requirements, 1-2 bales can be set. Unmanned baler selection of international famous brand electrical components, the whole machine quality is stable and reliable. Packing position: the position of electric eye can be adjusted as required. Unmanned baler can be used alone or with conveyor design automation and unmanned baling system, to meet the needs of customers.

Technical parameters

Model 1250
Size L1580*W600*H1900
Table Height 850mm
Machine weight 365Kg
Strapping speed >=55pcs/min
Strapping specifications Min.packing size W80mm*H60mm,Max.frame size
Power 600W.10A
Working environment Relative humidity≦90%,temperature 0-40℃, noise≦75dB(A)
Belt width/Belt thickness 5mm-9mm 0.5-0.6mm
Belt index dial specification Paper core inner diameter 200mm-210mm,outer diameter 400-450mm,width 175-190mm
Glue way Heat fusion
Glue connect way Bottom glue, glue area ≧90%,glue location deviation≦2mm
Tightness degree 0-45KG
Air pressure 0.4-0.6MPa
Max.strapping size L*W1200*H420

1250 Type Offline Carton Box Strapping Machine Bundle Corrugated Sheet1250 Type Offline Carton Box Strapping Machine Bundle Corrugated Sheet1250 Type Offline Carton Box Strapping Machine Bundle Corrugated Sheet
