Fiber Optic Loopback LC Single Mode Connector PC Polish Type L-com FOL-AT-LCUSM-20D with Dust Caps
Fiber Optic Loopback LC Single Mode Connector PC Polish Type L-com FOL-AT-LCUSM-20D with Dust Caps
Specifications
Description :
Fiber Optic Connector Accessories RoHS
Mfr. Part # :
FOL-AT-LCUSM-20D
Model Number :
FOL-AT-LCUSM-20D
Description

Product Overview

This Fiber Loopback LC Single Mode product is designed for fiber optic testing and network applications. It features LC connectors with a PC polish type and is accompanied by dust caps for protection. The product is compliant with EU RoHS directives. It is ideal for various testing scenarios requiring signal loopback functionality within single-mode fiber optic networks.

Product Attributes

  • Brand: L-COM, INC.
  • Connector Type: LC
  • Fiber Type: Single Mode
  • Polish Type: PC
  • Regulatory Compliance: EU RoHS Directive (most recent released version)
  • Included Accessories: Dust Cap (installed on each connector)

Technical Specifications

Model Number Attenuation Insertion Loss Return Loss Test Wavelength Overall Cable Length
FOL-AT-LCUSM-01D 1dB 0.2dB 50dB 1310 nm N/A
FOL-AT-LCUSM-02D 2dB 0.2dB 50dB 1310 nm N/A
FOL-AT-LCUSM-03D 3dB 0.2dB 50dB 1310 nm N/A
FOL-AT-LCUSM-05D 5dB 0.2dB 50dB 1310 nm N/A
FOL-AT-LCUSM-07D 7dB 0.2dB 50dB 1310 nm N/A
FOL-AT-LCUSM-10D 10dB 0.2dB 50dB 1310 nm N/A
FOL-AT-LCUSM-12D 12dB 0.2dB 50dB 1310 nm N/A
FOL-AT-LCUSM-15D 15dB 0.2dB 50dB 1310 nm N/A
FOL-AT-LCUSM-20D 20dB 0.2dB 50dB 1310 nm N/A
General Specifications:
Connector Polish Type PC
Test Wavelength 1310 nm
Insertion Loss 0.2dB
Return Loss 50dB

2310071613_L-com-FOL-AT-LCUSM-20D_C6450130.pdf
