20A M19 3 Pin Waterproof Connector Self Locking High Current Power Connector
20A M19 3 Pin Waterproof Connector Self Locking High Current Power Connector
20A M19 3 Pin Waterproof Connector Self Locking High Current Power Connector
20A M19 3 Pin Waterproof Connector Self Locking High Current Power Connector
20A M19 3 Pin Waterproof Connector Self Locking High Current Power Connector
20A M19 3 Pin Waterproof Connector Self Locking High Current Power Connector
Specifications
Brand Name :
Ulinkcon
Model Number :
M19
Certification :
CE/Rohs/TUV/UL
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T,D/P,L/C,D/A,,Western Union,MoneyGram
Supply Ability :
100000 pairs Montly
Delivery Time :
3~6working days
Packaging Details :
1.Plastic bag;2.Carton;3.As per customer's requirements
Current rating :
20A
Material :
PA66 and Brass tin plated
Rated voltage :
300V
Flame-resistant rating :
UL94-V0
Temperature :
-40~105℃
Specific Application Scenarios :
Solar PV Plants
Description
20A M19 3 Pin Waterproof Connector Self Locking High Current Power Connector

20A 3 Pin Power Cable Connector M19 DC Waterproof Quick Connector

Product Overview

M19 3 Pin 300V Waterproof Cable Connector Quick Lock For Power

Main Features
  • Item Name: M19 Waterproof Cable Connector
  • Specifications: Straight male-female mating, elbow male-female mating, front-mounted wire-to-board, rear-mounted wire-to-board, integrated injection molding
  • Coupling way: Self-locking
  • Pins number: 2-22 pins
  • Plug: Assembly type and Injection type available
  • Socket: Front Mount, Back Mount, PCB Mount
  • Waterproof grade: IP67/IP68
  • Connector type: Assembly lock screw; Assembly welding; Injection molding with cable
  • Wire gauge: 1.0-6.0mm² (18AWG-10AWG)
  • Wiring range Assembled: 6.0mm~16mm; Molding 6.0mm~16.5mm
  • Durability: 3000 times
  • Applicable temperature: -40℃~105℃
Quick Description
  • Core Specifications: Rated current 20A, M19 standard size, 3-pin configuration, designed for stable high-current power transmission.
  • Key Functions: Equipped with a reliable self-locking mechanism to prevent accidental disconnection; IP67 waterproof performance, suitable for harsh, outdoor and humid environments.
  • Core Advantages: Integrates reliability, waterproof protection and easy operation, serving as a cost-effective power connection solution for industrial and outdoor equipment.
Technical Specifications
Electrical Parameters
Number of Poles 3 pin
Current Rating 20A max.
Voltage Rating 300VAC max
Durability Voltage 1500VAC @ 60 s.
Technical Parameters
Contact Resistance 10 mΩ max
Insulation Structure 500 MΩ at 500VDC
Operating Temperature -40°C ~ +105°C
IP Class IP67 (1m / 30min) when mated
Mold Material PA66
Contact/Terminal Material Gold Plated Brass
Seal Material Silicone
Operation Parameters
Voltage Rating 600VAC max
Current Rating 15A max
Min Wire Size OD 3.0mm ~ 6.0mm
Max Wire Size OD 8.0mm ~ 10.0mm
Max.Cable Cross Section Area 0.5mm² ~ 2.5mm²
Design Sketch
20A M19 3 Pin Waterproof Connector Self Locking High Current Power Connector 20A M19 3 Pin Waterproof Connector Self Locking High Current Power Connector
Frequently Asked Questions
What shipping methods do you offer? How long is the delivery time?
We provide multiple shipping options: 1) Courier (DHL/UPS/FedEx): 3-7 working days for small parcels; 2) Air freight: 7-15 working days; 3) Sea freight: 20-45 working days. Delivery time varies by destination and shipping method.
Are your products certified? What certifications do you have?
All our products are certified by RoHS, CE, and other international standards. Specific certifications (e.g., FCC, UL) can be provided upon request based on your target market.
Can I have custom label?
Yes, of course, you can make your own private label and package. If you need to design the packaging, we also have professional designers to serve you.
