Specifications
Brand Name :
Ulinkcon
Model Number :
M16
Certification :
CE/Rohs
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T,D/A,D/P,MoneyGram,L/C
Supply Ability :
100000 pairs each month
Delivery Time :
3~6 working days
Packaging Details :
High Quality export carton
Number of Pins :
3Pin
Current :
10A max
Rated voltage :
300V
Waterproof Rating :
IP67
Color :
Red Blue White Black Yellow
Sealing Material :
Waterproof O-Ring
Description
3Pin Waterproof Panel Mount Connector M16 Push Locking Power Connector
3 Pin Power Connector Product Overview

Quick Release M16 3Pin Waterproof Circular Connector Wire To Board. A waterproof connector designed specifically for integrated power supply of equipment panels, compatible with M16 standard installation size.

M16 IP67 Waterproof Connectors Key Features
  • Push lock quick release system for easy operation
  • Multiple pin configurations available: 2Pin, 3Pin, 4Pin, 5Pin, 2+4Pin, 7Pin, 8Pin
  • Field assembly versions: wire to wire and wire to board options
  • High current rating up to 10A for long-term operation
  • Cable assembly service supported with customization options
  • OEM/ODM services available
Technical Specifications Of 3 Pin Power Connector
Electrical Parameters
Number of Poles 3Pin waterproof connector
Current Rating 10A max
Voltage Rating 300VAC max
Durability Voltage 1500VAC @ 60 s
Technical Parameters
Contact Resistance 10 mΩ max
Insulation Structure 500 MΩ at 500VDC
Operating Temperature -40°C ~ +105°C
IP Class IP67 (1m / 30min)
Mold Material PA66
Contact/Terminal Material Gold Plated Brass
Seal Material Silicone
3 Pin Male To Female Connector Design & Construction
  • Core Positioning: 3-pin precise power supply configuration for stable transfer between equipment panels and external power sources
  • High-Quality Materials: Weather-resistant and flame-retardant engineering plastic housing (V0-level flame retardancy, UV aging resistance)
  • Protection Performance: IP67 waterproof and dustproof rating with special sealing structure and high-elasticity waterproof rubber rings
  • Connection Design: Push-lock locking structure for easy operation, anti-vibration and anti-falling; M16 panel-mounted design
Application Industries
  • Communications Equipment
  • Product Coding Machines
  • Inventory Product Coding Systems
  • Inkjet Systems
  • Solar Systems
  • Industrial Inkjet Equipment
  • Electric Power Equipment
  • Laboratory Forensic & Pathology Equipment
  • Heavy Machinery
Production Dimension
3Pin Waterproof Panel Mount Connector M16 Push Locking Power Connector
Technical Details
3Pin Waterproof Panel Mount Connector M16 Push Locking Power Connector
Frequently Asked Questions
Who is responsible for customs clearance? Do you provide necessary documents?
We will provide complete customs clearance documents (commercial invoice, packing list, bill of lading, certification reports). Customs clearance fees and duties are borne by the buyer (EXW/FOB terms). We can assist with document preparation if needed.
Can I pay after receiving the goods?
For first-time cooperation, advance payment is required to ensure production smoothness. For long-term trusted clients, flexible payment terms can be discussed after several successful orders.
What is rated voltage?
Rated voltage also known as operating voltage, which mainly depend on the connector insulation material used, the spacing between the size of contact. Some of the components or devices in less than its rated voltage may not be completed to its functions.
