M25 5 Pin IP67 Circular Connectors 50A Plastic Male Female Plug Socket Connectors
M25 5 Pin IP67 Circular Connectors 50A Plastic Male Female Plug Socket Connectors
M25 5 Pin IP67 Circular Connectors 50A Plastic Male Female Plug Socket Connectors
M25 5 Pin IP67 Circular Connectors 50A Plastic Male Female Plug Socket Connectors
M25 5 Pin IP67 Circular Connectors 50A Plastic Male Female Plug Socket Connectors
M25 5 Pin IP67 Circular Connectors 50A Plastic Male Female Plug Socket Connectors
Specifications
Brand Name :
Ulinkcon
Model Number :
M25
Certification :
CE/Rohs
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T,D/A,D/P,MoneyGram,L/C
Supply Ability :
100000 pairs each month
Delivery Time :
3~6working days
Packaging Details :
High Quality export carton
Waterproof Rating :
IP67
Current :
50A
Temperature Range :
-40℃~+105℃
Number of Pins :
5Pin
Color :
Red/Black/Green
Electrical Functions :
Electrical Conductivity
Description

5 Pin Industrial Waterproof Power 300V M25 Cable Push Lock Male To Female Connector


Main Features


  • Push lock quick release system
  • Multic-core options: 2Pin,3Pin,4Pin,5Pin,3+2Pin,3+3Pin,3+9Pin,3+13Pin,5+2Pin and 2+20Pin available
  • Field assembly version:both wire to wire and wire to board options
  • High current rated waterproof connector good choice up to 50A for long time working
  • Cable assembly service supported, welcome to custom
  • OEM/ODM welcome


Quick Details of 2Pin waterproof Panel Connector


50A High Current Carrying Capacity
Designed for high-power transmission with a rated current up to 50A, providing stable and efficient power delivery for industrial equipment, power modules, and high-load electrical devices.

5-Pin Precise Electrical Configuration
Standard 5-pin layout with optimized terminal spacing and contact structure, ensuring low contact resistance, stable voltage output, and reliable signal or power transmission.

IP67 Waterproof & Dustproof Rating
Fully sealed circular structure effectively blocks dust, moisture, rain, and oil contamination. Suitable for long-term outdoor, humid, and harsh industrial environments.

Lightweight High-Strength Plastic Housing
Made of engineering-grade plastic material with high mechanical strength, heat resistance, corrosion resistance, and flame-retardant properties, while keeping the connector lightweight and easy to install.

Male & Female Plug‑Socket Matching System
Complete male and female connector set with precise alignment and tight fit, reducing poor contact, loosening, or wear during long‑term use.

M25 Standard Circular Interface
Adopts universal M25 circular size and mounting specifications, with high compatibility for panel mounting, cable assembly, and equipment replacement.

Shockproof & Anti‑Loosening Structure
Stable connection design enhances anti‑vibration and anti‑shaking performance, maintaining secure connection even under mechanical vibration and outdoor movement.


Electrical Parameters
Number of Poles 5Pin waterproof connector
Current Rating 50A max
Voltage Rating 600VAC max
Durability Voltage 1500VAC @ 60 s.


Application industries


  • Communications Application
  • product coding machines
  • inventory product coding
  • inkjet systems
  • Solar System
  • industrial inkjet equipment
  • Electric power equipment
  • Laboratory forensic&pathology equipment
  • Communications equipment
  • Heavy machinery


Technical Parameters
Contact Resistance 10 mΩ max
Insulation Structure 500 MΩ at 500VDC
Operating Temperature -40°C ~ +105°C
IP Class IP67 (1m / 30min)
Mold Material PA66
Contact/Terminal Material Gold Plated Brass
Seal Material Silicone
Operation Parameters
Voltage Rating 600VAC max
Current Rating 50A max
Min Wire Size OD 6.5mm ~ 10mm
Max Wire Size OD 10.5mm ~ 18mm
Max.Cable Cross Section Area 0.5mm2 ~ 6.0mm2


Production Dimension



More Technical Details



FAQ


Q1:What is rated voltage?

A1:Rated voltage also known as operating voltage, which mainly depend on the connector insulation material used, the spacing between the size of contact. Some of the components or devices in less than its rated voltage may not be completed to its functions.

Q2:Is there a discount for large - quantity orders?

A2: Yes, we offer tiered discounts for bulk orders. The more you order, the more competitive the price. Please inform us of your expected quantity for a customized quotation.

Q3:Is there a discount for large - quantity orders?

A3: Yes, we offer tiered discounts for bulk orders. The more you order, the more competitive the price. Please inform us of your expected quantity for a customized quotation.
