Low Current M19 Circular Waterproof Connector OEM Push Lock 14 Pin Data Connector
Low Current M19 Circular Waterproof Connector OEM Push Lock 14 Pin Data Connector
Low Current M19 Circular Waterproof Connector OEM Push Lock 14 Pin Data Connector
Low Current M19 Circular Waterproof Connector OEM Push Lock 14 Pin Data Connector
Low Current M19 Circular Waterproof Connector OEM Push Lock 14 Pin Data Connector
Low Current M19 Circular Waterproof Connector OEM Push Lock 14 Pin Data Connector
Specifications
Brand Name :
Ulinkcon
Model Number :
M19
Certification :
CE/Rohs/TUV/UL
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T,D/P,L/C,D/A,,Western Union,MoneyGram
Supply Ability :
100000 pairs Montly
Delivery Time :
3~6working days
Packaging Details :
1.Plastic bag;2.Carton;3.As per customer's requirements
Pin :
14Pin
Current rating :
5A For Data
Material :
Nylon
Protection level :
IP67
Flame-resistant rating :
UL94-V0
Sealing Material :
Waterproof O-Ring
Description
Low Current M19 Circular Waterproof Connector OEM Push Lock 14 Pin Data Connector
Product Overview

14 Pin Male Female Connector M19 300V Cable Connectors Waterproof

Quick Description
  • Core Specifications & OEM Service: Low current M19 circular waterproof connector with 14-pin design for data transmission, featuring push-lock connection and comprehensive OEM customization services including pin definition, contact spacing, shell size, and interface type modifications.
  • Circular Waterproof & Dustproof Performance: IP67 rated protection effectively isolates dust, moisture, and small particles, ensuring stable data transmission in humid, dusty, or outdoor environments.
  • Low Current Adaptability & Data Stability: Optimized for low-current data transmission with excellent signal anti-interference performance and reduced signal loss.
  • High-Quality Material & Structural Stability: Lightweight, high-strength engineering plastic shell with high-precision copper alloy pins for long-term reliable performance.
  • Push-Lock Design & Easy Operation: Quick connection system with push-lock mechanism for fast, secure installation and easy disassembly with anti-loosening performance.
Main Features
  • Push lock quick release system
  • Multicore options: 2Pin, 3Pin, 4Pin, 5Pin for Power
  • Power signal combinations: 3+2Pin, 3+3Pin, 3+4Pin, 3+5Pin, 3+9Pin and 2+20Pin
  • Signal options: 6Pin, 7Pin, 8Pin, 9Pin, 10Pin, 11Pin, 12Pin, 14Pin, 16Pin and 18Pin
  • Field assembly version with wire-to-wire and wire-to-board options
  • Current rated 5A for continuous operation
  • Cable assembly service supported
  • OEM/ODM customization welcome
Technical Specifications
Electrical Parameters
Number of Poles 14Pin
Current Rating 5A max
Voltage Rating 300VAC max
Durability Voltage 1500VAC @ 60 s
Technical Parameters
Contact Resistance 10 mΩ max
Insulation Structure 500 MΩ at 500VDC
Operating Temperature -40°C ~ +105°C
IP Class IP67 (1m / 30min) when mated
Mold Material PA66
Contact/Terminal Material Gold Plated Brass
Seal Material Silicone
Operation Parameters
Voltage Rating 300VAC max
Current Rating 5A max
Min Wire Size OD 3.0mm ~ 6.0mm
Max Wire Size OD 8.0mm ~ 10.0mm
Max Cable Cross Section Area 0.5mm² ~ 2.5mm²
Application Industries
  • Growth Lights
  • Communications Application
  • Product coding machines
  • Inventory product coding
  • Inkjet systems
  • Solar System
  • Industrial inkjet equipment
  • Electric power equipment
  • Laboratory forensic & pathology equipment
  • Communications equipment
  • Heavy machinery
Design Sketch
Low Current M19 Circular Waterproof Connector OEM Push Lock 14 Pin Data Connector Low Current M19 Circular Waterproof Connector OEM Push Lock 14 Pin Data Connector
Frequently Asked Questions
Q: Are you a factory or trading company?
A: We are a factory. Located in Ulinkcon Industrial Park, Bao'an District, Shenzhen, China
Q: How do I place an order? What is the process?
A: The order process is simple: 1) Confirm product details and get a proforma invoice (PI); 2) Make the down payment as agreed; 3) We start production and update you with progress; 4) Pay the balance before shipment; 5) Arrange delivery and provide tracking information.
Q: Can I pay after receiving the goods?
A: For first-time cooperation, advance payment is required to ensure production smoothness. For long-term trusted clients, flexible payment terms can be discussed after several successful orders.
Q: Is there a discount for large-quantity orders?
A: Yes, we offer tiered discounts for bulk orders. The more you order, the more competitive the price. Please inform us of your expected quantity for a customized quotation.
