M19 High Current DC 20A IP67 Solar Connectors 3 Pin Quick Lock Connector
M19 High Current DC 20A IP67 Solar Connectors 3 Pin Quick Lock Connector
M19 High Current DC 20A IP67 Solar Connectors 3 Pin Quick Lock Connector
M19 High Current DC 20A IP67 Solar Connectors 3 Pin Quick Lock Connector
M19 High Current DC 20A IP67 Solar Connectors 3 Pin Quick Lock Connector
M19 High Current DC 20A IP67 Solar Connectors 3 Pin Quick Lock Connector
M19 High Current DC 20A IP67 Solar Connectors 3 Pin Quick Lock Connector
M19 High Current DC 20A IP67 Solar Connectors 3 Pin Quick Lock Connector
Specifications
Material :
PA66 and Brass tin plated
MOQ :
Negotiation
Certification :
CE/Rohs/TUV/UL
Current rating :
20A For Power
Supply Ability :
100000 pairs Montly
Delivery Time :
3~6working days
Price :
Negotiation
Type :
Wire To Wire/Board
Model Number :
M19
Rated voltage :
300V
Place of Origin :
China
Flame-resistant rating :
UL94-V0
Packaging Details :
1.Plastic bag;2.Carton;3.As per customer's requirements
Temperature :
-40~105℃
Brand Name :
Ulinkcon
Payment Terms :
T/T,D/P,L/C,D/A,Western Union,
Description
20A 3 Pin Power Connector M19 DC Waterproof Quick Connector
Product Overview
The M19 3Pin 20A high-current solar connector is a professional DC power connection component customized for photovoltaic power supply systems. Featured with a dedicated 3-pin pure DC power structure, it focuses on high-power transmission demands of solar panels and outdoor energy storage equipment. Equipped with a thread-free Quick Lock self-locking structure, it supports tool-free fast plug-and-lock connection. With IP67 all-weather waterproof grade and excellent outdoor aging resistance, it is professionally optimized for long-term sun exposure, rain erosion and drastic temperature changes, serving as a reliable and low-loss power connection solution for outdoor solar and DC power systems.
Main Features
  • Item Name: M19 Waterproof Cable Connector
  • Specifications: Straight male-female mating, elbow male-female mating, front-mounted wire-to-board, rear-mounted wire-to-board, integrated injection molding
  • Coupling way: Self-locking
  • Pins number: 2-22 pins
  • Plug: Assembly type and Injection type available
  • Socket: Front Mount, Back Mount, PCB Mount
  • Waterproof grade: IP67/IP68
  • Connector type: Assembly lock screw; Assembly welding; Injection molding with cable
  • Wire gauge: 1.0-6.0mm² (18AWG-10AWG)
  • Wiring range Assembled: 6.0mm~16mm; Molding 6.0mm~16.5mm
  • Durability: 3000 times
  • Applicable temperature: -40℃~105℃
Quick Description
  • 20A High-Current DC Stable Transmission: Optimized for photovoltaic DC power supply characteristics, the connector adopts thickened high-purity copper terminals with ultra-low conduction resistance. It maintains stable 20A continuous DC output with low temperature rise and minimal power loss under full load. It effectively supports long-term high-power operation of solar modules and outdoor energy storage devices without voltage fluctuation or overload failure.
  • Simplified 3-Pin Pure Power Architecture: The streamlined 3-core pure power layout eliminates redundant signal pin interference, ensuring purer and safer DC circuit transmission. It avoids circuit disorder and poor contact risks common in photovoltaic systems, perfectly matching the non-stop working mode of outdoor solar power supply equipment and improving overall electrical safety.
  • Tool-Free Quick Lock Self-Locking Design: The upgraded elastic buckle structure enables one-step insertion locking and simple press release. No tools or thread twisting are required, greatly simplifying installation and maintenance for high-altitude and field solar projects. The stable locking tension provides excellent anti-loosening performance against equipment vibration and cable pulling.
  • IP67 Full Ingress Protection for Outdoor Solar Scenarios: Built with integrated high-elastic sealing gaskets, the connector achieves gapless sealing after locking. It fully resists rainwater soaking, dust accumulation, dew and moisture corrosion, ensuring stable circuit connection in open-air photovoltaic power stations, roof solar systems and outdoor energy storage equipment all year round.
  • UV-Resistant & Anti-Aging Industrial Housing: Adopting weather-resistant flame-retardant material exclusive for solar equipment, the housing withstands long-term outdoor UV radiation and extreme temperature cycles. It avoids yellowing, cracking and structural deformation, maintaining stable insulation and mechanical performance for prolonged outdoor service life.
  • Large-Caliber M19 Structure for Heavy-Duty Wiring: The widened M19 cavity structure accommodates large-gauge solar dedicated cables without extrusion or damage. With stronger structural bearing capacity, it perfectly fits high-power photovoltaic circuits and solves the limitations of small-size connectors with insufficient load and narrow wiring space.
Technical Specifications
Electrical Parameters
Number of Poles 3 pin
Current Rating 20A max.
Voltage Rating 300VAC max
Durability Voltage 1500VAC @ 60 s.
Technical Parameters
Contact Resistance 10 mΩ max
Insulation Structure 500 MΩ at 500VDC
Operating Temperature -40°C ~ +105°C
IP Class IP67 (1m / 30min) when mated
Mold Material PA66
Contact/Terminal Material Gold Plated Brass
Seal Material Silicone
Operation Parameters
Voltage Rating 600VAC max
Current Rating 15A max
Min Wire Size OD 3.0mm ~ 6.0mm
Max Wire Size OD 8.0mm ~ 10.0mm
Max.Cable Cross Section Area 0.5mm² ~ 2.5mm²
Design Sketch
M19 High Current DC 20A IP67 Solar Connectors 3 Pin Quick Lock Connector M19 High Current DC 20A IP67 Solar Connectors 3 Pin Quick Lock Connector
