22mm OD USB 2.0 27-Way Electricity Slip Ring with 2 Million RPM Service Life and Flange Mount
22mm OD USB 2.0 27-Way Electricity Slip Ring with 2 Million RPM Service Life and Flange Mount
Specifications
Brand Name :
GUREN
Model Number :
WX22-36PS-GRCO161
Certification :
ISO9001.CE.RoHS
Place of Origin :
China
MOQ :
1
Price :
＄19-199
Payment Terms :
L/C,D/A,D/P,T/T
Supply Ability :
1K units/week
Delivery Time :
3 weeks ARO
Packaging Details :
Standard/On Request
outer diameter :
22mm
length :
54.5mm
Signal support types :
Analog video signal 、USB 2.0 、Ethernet signal、 Low-speed digital signal、 Analog signal
Number of circuits :
27-way electricity
Contact material :
Gold-Gold
Service life :
2 million rpm
Description
22mm OD Electrical and USB Combination Slip Rings Flange Mount
This USB slip ring features a USB connector and 24 circuits, capable of passing USB signals and 2A current. The injection-molded housing with 22mm outer diameter and cap-style design ensures easy installation. With a rotation speed of 150 rpm and 220V compatibility, it's ideal for industrial applications.
Key Features
  • Combined power and USB transmission:
    • USB 2.0+ compatible signal channel for uninterrupted data transmission
    • 24 power circuits (2A each) for multiple device connections
    • 220V maximum operating voltage for industrial environments
  • Compact and easy installation:
    • 22mm outer diameter for space-constrained applications
    • Injection-molded housing for superior sealing and durability
    • Tool-free cap-style mounting for quick installation
  • High performance:
    • 150 rpm rotation speed for medium/low-speed applications
    • Optimized contact design for stable signal transmission
Technical Specifications
Parameter Value
Dielectric strength 100VCA@50Hz,60s
Insulation resistance ≥500MΩ/100VDC
Dynamic resistance change value ＜0.01Ω
Rated voltage 0～220VDC/VAC
Wire Specifications AWG28#Teflon wire
Wire length Rotor 250mm; stator 250mm (reference value)
Operating temperature -30℃～+70℃
Operating humidity 0～85%RH
Protection level IP51
Shell material PBT
Rotational torque 0.05N.m,+0.01N.m/6-way
Service life 2 million rpm
Product Dimensions
22mm OD USB 2.0 27-Way Electricity Slip Ring with 2 Million RPM Service Life and Flange Mount
Product Views
22mm OD USB 2.0 27-Way Electricity Slip Ring with 2 Million RPM Service Life and Flange Mount 22mm OD USB 2.0 27-Way Electricity Slip Ring with 2 Million RPM Service Life and Flange Mount
Applications
Ideal for drones, stabilizers, smart home devices, security monitoring systems, photography/videography equipment, robotics, test instruments, turntables, and automation systems requiring simultaneous USB data and power transmission.
