COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
Specifications
Brand Name :
Comelink
Model Number :
COME-3630X
Certification :
ROHS/ISO9001/CE
Place of Origin :
CHINA
MOQ :
100 PCS
Price :
USD 100 PCE
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500+PCS+per week
Delivery Time :
7 days
Packaging Details :
Carton
Power Source :
DC 12V/1.5A
Power Consumption :
≤15 W
Distance :
0~ 20Km Max
Typical Solution :
FTTO/FTTB/FTTH/FTTR
Optical output power :
-1~+4dBm
Receiving sensitivity :
< -25dBm
Description

XGPON Combo FT3630X is a FTTR all-optical home solution product independently developed by Shenzhen Kexint Technology Co., Ltd. It is a home terminal product that integrates Combo PON, VoIP, and high-speed WiFi 6. It can serve as a multi-service access and control center for households, providing users with high-speed internet access, voice call services, and WIFI. Besides, it solves the problems of low transmission rate, poor wireless coverage, and roaming cards in traditional home wireless networking, providing a true whole house WiFi gigabit broadband access experience for home users.

The FTTR home terminal series products mainly consist of two parts: the home all optical main gateway and the sub gateway.

FTTR Home Terminal All Optical Main Gateway Product Form:

FTTR all optical main gateway XGPON Combo FT3630X: XG-PON Combo uplink,

1 * GPON, 4 * GE electrical port,

1 * USB, Dual AX3000 WiFi6 (2x2MIMO),

1 * POTS voice port

COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU

Specification:

ITEM
All-Optical Main Gateway-XGPON Combo FT3630X
Port
Uplink Port: XGPON Combo Interface
line Rate: XGPON downlink 9.95328Gbps, uplink 2.48832Gbps；GPON downlink2.48832Gbps,uplink 1.24416Gbps；
Downlink Port:1*GPON,1 * GPON, cascaded optical routing through splitters, can support up to 16 optical routing accesses.
4 * GE port, 1 * USB; AX3000 Dual band WiFi6(2x2MIMO); 1 * POTS voice port
Port Working Wavelength of Xgpon Combo
Complies with ITU-T G.987/G.988 standards
Central wavelength:XGPON downlink 1577nm ,uplink1270nm；
GPON downlink 1490nm,uplink 1310nm
Optical Interface Type
SC/UPC
Processor Capability
Dual Core 1G Hz
RAM
4Gbit SDRAM
Storage
2Gbit Nand Flash
EasyMesh
Support
VLAN
Support
Power Supply
Ac: Input 90 ~ 264V, 47 ~ 67Hz;
Adapter output DC: 12V/2A
Consumption
≤15W
Weight
≤0.7kg
Dimension(L*W*H)
240*160*41(cm)
Environmental Parameters
Operating Temperature:-5°C～45°C
Storage Temperature:-40°C～70°C
Relative Humidity:10%～90%,no condensation
Button
Reset Button, WiFi Switch Button, WPS

COMELINK FTTR Gigabit Ethernet Smart Mini ONT 4GE POTS 2.4G 5G WIFI6 XPON ONU
