Specifications
Brand Name :
Comelink
Model Number :
G5D
Certification :
ROHS/ISO9001/CE
Place of Origin :
CHINA
MOQ :
100 PCS
Price :
USD 26.5 PCE
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500+PCS+per week
Delivery Time :
7 days
Packaging Details :
Carton
Color :
White
Firmware Language :
English
Optical Wavelength :
T*1310nm,Rx 1490nm
Power supply :
DC 12V 1A 1.5A
Adaptor Type :
SC/UPC SC/APC
Warranty Time :
2 years
Description
OUR ONU :
G5D is designed and manufactured by Shenzhen KEXINT Technology Co.,Ltd, designed for fulfilling FTTH (Fiber To The Home) and triple play service demand of fixed network operators. The box is based on the mature Gigabit GPON technology, which has high ratio of performance to price, and the technology of 802.11n WiFi (2T2R), Layer 2&3 and high quality VoIP as well. It is highly reliable and easy to maintain, with guaranteed QOS for different service. And It is fully compliant with technical regulations such as ITU-T G.984.x and technical requirement of GPON Equipment (V2.1 and above version) from China Telecom.

Port characteristics:

►Complies with ITU-T G.984.1, ITU-T G.984.2, ITU-T G.984.3 and ITU-T G.984.4 provides comprehensive GPON network compatibility
► Downstream rates of up to 2.488Gbps and upstream rates up to 1.244Gbps
► Fiber access and gigabit port provide incredibly fast transfer speeds
► Supports OMCI (ONU Management CONUrol Interface) remote management
Specification:
Item
Description
GPON Standards
ITU-T G.984.1, G.984.2, G.984.3, G.984.4
Chipset
Realtek RTL9603C+RTL8192
PON Interface
1 SC/UPC Port
Data Rates & Wavelength
Upstream:1.244Gbps, 1310nm
Downstream:2.488Gbps, 1490nm
RX sensitivity
< -28dBm @ 1490nm
Distance
0~ 20Km Max
LAN interface
1*10/100/1000Mbps
3*10/100Mbps
Auto adaptive Ethernet interfaces, Full/Half Duplex, RJ45 connectors
WLAN
Compliant with IEEE802.11b/g/n, 300Mbps, 2T2R
two internal antenna,or external antenna(optional)
POTS interface
1 FXS, RJ11 connectors
External Power Supply
DC 12V/1A
Dimensions (Length * Width * Height)
180mm×130mm×50mm
Weight (Full-Loaded)
≤0.4kg
Environmental Requirements
Working temperature: 0°C～40°C
Storage temperature: -40°C～70°C
Relative humidity: 10%～90%, non-condensing

Special features:

Service Flow Classification based on VLAN

Schedule rules Support SP/WRR
Upstream Priority Label Support 802.1D User Priority
Rate Limit and Traffic shaping
Congestion CONUrol Support Tail-Drop

More:

Upstream and Downstream FEC
Dynamic Bandwidth Allocation(DBA) support NSR/SR
Up to 7 T-CONUs and 4095 GEM Ports
Optical power detection, Dying Gasp
Terminal Silent mechanism
802.3az EEE Energy Conservation
