Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Specifications
Brand Name :
comelink
Model Number :
QSFP+ LR4
Place of Origin :
China
MOQ :
1 PC
Price :
200 dollars
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
3-5 workdays
Form Factor :
QSFP+
Max Data Rate :
41.25Gbps (4x 10.3125Gbps)
Wavelength :
1310nm
Max Cable Distance :
10km
Description

The QSFP+ module is designed for use in 40GBASE Ethernet throughput up to 10km over single mode fiber (SMF) using a wavelength of 1310nm via duplex LC connectors. This transceiver is compliant with SFF-8436 QSFP+ MSA and RoHS standards. Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP+ MSA, to allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is suitable to be used in various applications, such as data centers, high-performance computing networks, enterprise core and distribution layer applications.

Specifiction

Form Factor
QSFP+
Max Data Rate
41.25Gbps (4x 10.3125Gbps)
Wavelength
1310nm
Max Cable Distance
10km
Connector
Duplex LC
Media
SMF
Transimitter Type
DFB CWDM
Receiver Type
PIN
TX Power
-7~2.3dBm
Receiver Sensitivity
<-13.7dBm
Power Budget
6.7dB
Receiver Overload
2.3dBm
Power Consumption
≤2.5W
Extinction Ratio
>3.5dB
Host FEC
Supported
Bit Error Ratio (BER)
1E-12
Industrial Temperature Range
-40 to 85°C (-40 to 185°F)
Protocols
QSFP+ MSA, SFF-8436, IEEE 802.3ba

Product Highlights

Built-in Semtech Chip, Max. Power Consumption 2.5W
Tested in Targeted Switches for Superior Performance, Quality, and Reliability
High-Speed Electrical Interface Compliant to IEEE 802.3ba
Compliant to SFF-8436 and QSFP MSA
Interoperable with Other IEEE-compliant 40GBASE Interfaces as Applicable
Hot Pluggable QSFP+ Form Factor
Digital Optical Monitoring Capability for Strong Diagnostic Capabilities

Connectivity Solution

Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module

Feature

Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module

40G Connectivity for Data Center
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Tested in Host Devices for Proven Interoperability
Every unit is quality tested for compatibility in the targeted switch environment, which guarantees flawless operations.
Cisco Compatible 40GBASE-LR4 QSFP+ 1310nm 10km DOM Duplex LC/UPC SMF Optical Transceiver Module
Comprehensive Testing Increases Reliability
Qualified through a rigorous process with advanced equipments to ensure you get the high quality and reliable optics.
