Specifications
Brand Name :
ADJIG
Model Number :
QSP16020
Place of Origin :
Chongqing, China
MOQ :
1
Price :
41 - 69 USD per item
Payment Terms :
T/T,L/C
Supply Ability :
Less than 30 pieces, shipped within 5-7 days. More than 30 items will be shipped within 25-30 days.
Delivery Time :
7-10 days
Packaging Details :
Carton/wooden crate
Material :
High-quality steel
Installation :
Easy to install and use
Maintenance :
Low maintenance required
Size :
Customizable
Adjustability :
Easily adjustable for different workpieces
Type :
Fixture
Durability :
Long-lasting
Convenience :
Saves time and effort in changing workpieces
Usage :
Quickly change workpieces in a production line
Precision :
Ensures accurate positioning of workpieces
Efficiency :
Increases production speed
Description
Ball Lock Mounting System Manual High-precision Ball Lock Shaft
Features, Benefits, & Product Specifications:
  • Material: 4340 Steel
  • Finish: Black Oxide
  • Heat Treat: Shanks: 40-45 RC
  • Operating Temperature Range: -20°F to 400°F (-30°C to 200°C)

Repetitive positioning accuracy<± 0.013mm;

The Ball Lock Mounting System is a manual, high-precision solution for rapid and repeatable component positioning. This system utilizes a precision-machined shaft with locking balls that engage with a corresponding mount, ensuring rigid and accurate location every time. Ideal for fixture plates, molds, and automated applications, it allows for tool-less changes in seconds, drastically reducing downtime. The manual operation provides a simple, reliable mechanism for achieving micron-level repeatability without complex hydraulics or pneumatics. Enhance your production efficiency with this robust ball lock shaft, designed for seamless integration and unparalleled accuracy in demanding industrial environments.

PART NUMBER CLAMPING FORCE(KN) TIGHTENINGI TOROUE (KN) TIGHTENINGI ADAPTER PLATE (Nm) (±0.13) ΦD1 ΦD2 H H1 M SW

WEIGHT

(kg)
QSP-16020 5.3 4.5 20 32 16 36.5 8 M6 3 100
QSP-16025 5.3 4.5 25 32 16 41.5 8 M6 3 110
QSP-20020 13.3 5.3 20 40 20 39.5 10 M6 3 200
QSP-20025 13.3 5.3 25 40 20 44.5 10 M6 3 230
QSP-25020 30 11 20 45 25 44 10 M8 4 270
QSP-25025 30 11 25 45 25 49 10 M8 4 300
QSP-30020 44 18 20 50 30 49 13 M10 5 360
QSP-20025 44 18 25 50 30 54 13 M10 5 400
