Screw Locator Locating Pin Fixture CNC Components Manual Quick Change Clamp

Product Features:

1. Simple Manual Setup
2. High-Precision Location.
3. Locating Repeatability 3µ.
4. Min. Tightening Force 1200-3000 N.
5. Max. Loading Weight - Horizontal Mounting: 100-800kg, Vertical Mounting: 20-160kg

Screw Locator with a movable taper sleeve performs high-precision locating of pallets and

plates simply by fastening the bolts, Cut Pin, Tightening Bolt Size M12, Option PC.

This manual quick-change clamp system, featuring a robust screw locator and precision locating pin, redefines efficiency in CNC fixture setup. The integrated components work in unison to provide rapid, tool-less changes and micron-level repeatable positioning. The screw locator securely clamps the workpiece, while the hardened locating pin ensures perfect alignment, eliminating errors. Ideal for modular fixtures and high-mix production, this solution drastically reduces non-cutting time between jobs. Achieve unparalleled accuracy, enhance workflow flexibility, and maximize machine uptime with this essential, high-performance workholding combination for demanding manufacturing environments.

Model SDJT0080 SDJT0100 SDJT0120 SDJT0160
Repeatability accuracy 0.003
0.2 0.3
Load Capacity Horizontal installation (g) 400 500 600 800
Vertical installation (g) 80 100 120 160
Clamping force (KN) 1.8 2 2.5 3
Clamping sequence Positioning pin (SDJT-PD) → Orientation pin (SDJT-PC)
Temperature (℃) 0-70
Weight Locating pin (g) 4 5 15 25
Locating sleeve (g) 10 11 36 50
