2P 230V ATS Changeover Device Dual Power 80A Din Rail PC Type Automatic Transfer Switching
2P 230V ATS Changeover Device Dual Power 80A Din Rail PC Type Automatic Transfer Switching
2P 230V ATS Changeover Device Dual Power 80A Din Rail PC Type Automatic Transfer Switching
2P 230V ATS Changeover Device Dual Power 80A Din Rail PC Type Automatic Transfer Switching
2P 230V ATS Changeover Device Dual Power 80A Din Rail PC Type Automatic Transfer Switching
2P 230V ATS Changeover Device Dual Power 80A Din Rail PC Type Automatic Transfer Switching
2P 230V ATS Changeover Device Dual Power 80A Din Rail PC Type Automatic Transfer Switching
2P 230V ATS Changeover Device Dual Power 80A Din Rail PC Type Automatic Transfer Switching
2P 230V ATS Changeover Device Dual Power 80A Din Rail PC Type Automatic Transfer Switching
2P 230V ATS Changeover Device Dual Power 80A Din Rail PC Type Automatic Transfer Switching
2P 230V ATS Changeover Device Dual Power 80A Din Rail PC Type Automatic Transfer Switching
2P 230V ATS Changeover Device Dual Power 80A Din Rail PC Type Automatic Transfer Switching
Specifications
Phase :
Single Phase
Function :
Automatic Transfer Switch Generator ATS
Rate Current :
80A
Rated Current :
80A
Frequency :
50Hz/60Hz
Operation type :
Automatic Conversion
Brand Name :
OEM
Product name :
Automatic Transfer Switch
Pole :
2P
Rated voltage :
AC220V
Model Number :
MEH3-80AE/2P
Place of Origin :
Zhejiang, China
Application :
Households, Industrial Power
Price :
$12-12.50 / piece
Number of Pole :
2
Frame Current :
63 A
Switching Time :
50ms
Certificate :
CE
MOQ :
200 pieces
Type :
PC, Double Power Source
Description
Specification
Case grade 80
Rated operating current le(A) 10A 16A 20A 25A 32A 40A 50A 63A 80A
Rated insulation voltage Ui 690V
Rated impulse withstand voltage Uimp 8kV
Rated working voltage Ue 230VAC
Rated frequency 50/60Hz
Class PC class: can be switched on an loaded without generating short-circuit current
Pole number 2P,4P
Rated short-circuit current lq 50kA
Short circuit protection device (fuse) RT16-00-63A
Rated impulse withstand voltage 8kV
Control circuit Rated control voltage Us:AC220V,50Hz
Normal working conditions: 85%Us-110%Us
Auxiliary circuit AC 220V/110V 50Hz le=5A
Contactor change-over time <50ms
Operation change-over time <50ms
Return change-over time <50ms
Power off time <50ms
Change-over operation time <50ms
Mechanical life ≥5000 Times
Electrical life ≥1500 Times
Usage category AC-31B
