Pvc Green Color Hot Dipped Galvanized Razor Wire Concertina Bto-22
Pvc Green Color Hot Dipped Galvanized Razor Wire Concertina Bto-22
Pvc Green Color Hot Dipped Galvanized Razor Wire Concertina Bto-22
Pvc Green Color Hot Dipped Galvanized Razor Wire Concertina Bto-22
Specifications
Brand Name :
XR
Model Number :
WRW
Certification :
CE
Place of Origin :
CHINA
MOQ :
6 Square Meters
Price :
Negotiated
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
500 Tons Per Month
Delivery Time :
7-10 days after get the payment
Packaging Details :
Pallet
Name :
Pvc Green Color Hot Dipped Galvanized Razor Wire Concertina Bto-22
Zinc Coated :
Galvanized Wire:8-60g/m2;Blade:40-60g/m2 Or As Customer's Req
Material :
Galvanized And Stainless Steel
Mesh Aperture :
75x150Mm
Panel Size :
1x2M，2x4M，4x8M
Barb Length :
BTO10 12 18 22 28 30 CBT60 65
Height :
1.2/1.5/1.8/2.1/2.4M
Application :
Security And Safety
Description

PVC Green Color/ Hot Dipped Galvanized BTO-22 Concertina Razor Barbed Wire

Concertina Wire Materials

  1. Blade: steel plate by one-time punching moulding
  2. or stainless steel plate by one-time punching moulding
  3. Wire: hot dipped galvanized metal wire
  4. hot dipped galvanized steel wire or stainless steel wire

Concertina Wire Surface Treatment

  1. Electro Galvanzied
  2. Hot Dip Galvanized
  3. PVC Coated

Razor Wire Fence Hole Type

  1. Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.
  2. Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.

Peference

number

Thickness

(mm)

Wire dia

(mm)

Barb length

(mm)

Bard width

(mm)

Bard spacing

(mm)
BTO-12 0.5±0.05 2.5±0.1 12±1 15±1 26±1
BTO-15 0.5±0.05 2.5±0.1 18±1 15±1 33±1
BTO-22 0.5±0.05 2.5±0.1 22±1 15±1 34±1
BTO-30 0.5±0.05 2.5±0.1 30 18 45±1
CBT-60 0.6±0.05 2.5±0.1 60±2 32±1 100±2
CBT-65 0.6±0.05 2.5±0.1 65±2 21±1 100±2

Barbed Tape Wire Specification
Loop Outside Diameter No. of Loops Standard Length per Coil Type Notes
450mm 33 7-8M CBT-60.65 Single coil
500mm 56 12-13M CBT-60.65 Single coil
700mm 56 13-14M CBT-60.65 Single coil
960mm 56 14-15M CBT-60.65 Single coil
450mm 56 8-9m(3 CLIPS) BTO-10.12.18.22.28.30 Cross type
500mm 56 9-10M (3 CLIPS) BTO-10.12.18.22.28.30 Cross type
600mm 56 10-11M(3 CLIPS) BTO-10.12.18.22.28.30 Cross type
600mm 56 8-10M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
700mm 56 10-12M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
800mm 56 11-13M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
900mm 56 12-14M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
960mm 56 13-15M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
980mm 56 14-16M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type

Concertina Razor Wire Character

  • 1.Easy installation;
  • 2.Use a long time
  • 3. Strong Protection

Concertina Razor Wire Advantages:

Long Life Razor Wire Material
Security Can Be Installed Extremely Fast And With Little Equipmen
Allowing Repairs To Be Carried Out Without Compromising Perimeter Security
High Security Barbed Razor Wire With The Sharp Razor Guarantees
A High Quality Whilst Retaining High Security.
