16bar Reactor Mechanical Seal 232PSI M461K Eagleburgmann Cartex
16bar Reactor Mechanical Seal 232PSI M461K Eagleburgmann Cartex
16bar Reactor Mechanical Seal 232PSI M461K Eagleburgmann Cartex
16bar Reactor Mechanical Seal 232PSI M461K Eagleburgmann Cartex
16bar Reactor Mechanical Seal 232PSI M461K Eagleburgmann Cartex
16bar Reactor Mechanical Seal 232PSI M461K Eagleburgmann Cartex
16bar Reactor Mechanical Seal 232PSI M461K Eagleburgmann Cartex
16bar Reactor Mechanical Seal 232PSI M461K Eagleburgmann Cartex
Specifications
Delivery Time :
15 working days
Model Number :
M461K
Pressure :
p1 = vacuum ... 16 bar (232 PSI), p3 = max. 18 bar (261 PSI)
Payment Terms :
T/T,Western Union,D/P,D/A,L/C
Seats :
Silicon carbide, FDA conform
Certification :
ISO9001
Temperature :
t1 = -40 °C ... +200 (250*) °C(-40 °F ... +392 (482*) °F)
MOQ :
1pc
Packaging Details :
Carton
Seal faces :
Carbon graphite or Silicon carbide, FDA conform
Supply Ability :
1000000/Month
Secondary seals and metallic parts :
application and customer's requirement
Place of Origin :
CHINA
Sliding velocity :
vg = 0 ... 5 m/s (0 ... 16 ft/s)
Brand Name :
BESTSEAL
Shaft diameter :
d1 = 40 ... 160 mm (1.57" ... 6.30")
Description

EagleBurgmann M461K Reaction Kettle Cartridge Mechanical Seal Liquid lubricated Seals for Agitators

Mechanical Seals

Agitator seals

Liquid lubricated seals

M461K

Advantages

  • Ready-to-fit and factory-tested unit
  • Available with or without bearing
  • Suitable for standardizations
  • Seal can be applied at higher pressure and rotating speed than specified by DIN
  • The seal can be lifted off the glass-lined flange as a complete cartridge. The sensitive glass lined basic flange remains mounted on the vessel.
  • ATEX certification on request

Features

  • Cartridge double seal for top entry drives
  • For glass-lined vessels
  • Liquid lubricated
  • Self-closing on product side
  • Unbalanced
  • Independent of direction of rotation
  • Multiple springs rotating

Standards and approvals

  • FDA
  • ATEX
  • DIN 28138 (mechanical seals for agitator shafts)
  • DIN 28136 T3 (for glass-lined vessels)
  • DIN 28137 T2 (flange connection for glass-lined vessels)
  • DIN 28159 (shaft end for glass-lined vessels)

Recommended applications

  • Petrochemical industry
  • Chemical industry
  • Pharmaceutical industry
  • Food and beverage industry
  • Agitators
  • Reactors

BESTSEAL — Your Reliable Partner for Mechanical Seals

BESTSEAL Advantage:
15 years Focused in mechanical seal manufacturing
3 hours Quotation response only takes 3 hours
1 day Provide production assembly drawings
1 piece MOQ, One piece can also be produced
15-20 working days The production cycle only takes 15-20 working days
real-time Real time synchronization of production progress

BESTSEAL Agitator seals

Your Fast-Track Alternative to EagleBurgmann M461K

Custom Cartridge Mechanical Seals — From Drawing to Delivery in 15–20 Working Days
