Specifications
Model Number :
Type 3740
Pressure Limits :
Excursion: 450 psi(g)/31.0 bar(g), Continuously: 300 psi(g)/20.7 bar(g)
Place of Origin :
CHINA
RUNOUT :
0.060"/1.52mm TIR
Certification :
ISO9001
Speed Limits :
3500fpm/17.8m/s
MOQ :
1pc
Packaging Details :
Carton
Recommended Applications :
Process pumps, Mixer and agitators, Other rotating equipment
Mating Ring Adapter Assembly :
316 Stainless Steel, Alloy 20, Monel ®, Titanium, Inconel ® 625
Supply Ability :
1000000/Month
Mating Ring :
Silicon Carbide
Springs :
Alloy C-276
Payment Terms :
T/T,Western Union,D/P,D/A,L/C
Primary Ring :
Carbon, Silicon Carbide
Elastomers :
Ethylene Propylene, Fluoroelastomer
Spring Adapter Assembly Set :
316 Stainless Steel, Alloy 20, Monel ®, Titanium, Inconel ® 625
Delivery Time :
15 working days
Gland Plate Assembly :
316 Stainless Steel, Alloy 20, Monel ®, Titanium, Inconel ® 625
Retaining Ring :
Alloy X-750
Brand Name :
BESTSEAL
Temperature Limits :
250°F/121°C
Description

John Crane Type 3740 Cartridge Split Mechanical Seal for Process Pumps Mixer and Agitators

Cartridge Mechanical Seals

Split Seals

Type 3740

Advanced Design, Wet-running Cartridge O-ring Split Seal

The Type 3740 mechanical seal family, are split seals that use the latest modular split seal technology from John Crane. This combines the unique design requirements for wet-running and dry-running services onto one common seal platform.

The Type 3740 wet-running split seal incorporates the best features for fast and easy seal installation, while providing reliable seal performance in demanding pump and other rotating equipment fluid services.

Fully compliant with NSF-61 standards for clean drinking water services.

Features

  • Factory-preassembled rotor assembly for fast and easy, yet precise, rotating face installation.
  • Separate stationary seal face for visual assurance the halves are correctly aligned.
  • Factory-preassembled gland plate assembly for easy, single-step installation.
  • Balanced primary ring design for increased pressure capability.
  • Premium seal face materials for optimal performance.
  • Captive socket head cap screws to eliminate lost or dropped screws.
  • Same-side screws on all hardware for easy access and faster installation.
  • Dovetail O-ring grooves to contain all O-rings without requiring adhesives.
  • Fast and easy field repair kits that do not require any special tools, adhesives or procedures.
  • Two connections in the gland to provide easy access for flush piping.

BESTSEAL — Your Reliable Partner for Mechanical Seals

BESTSEAL Advantage:
15 years Focused in mechanical seal manufacturing
3 hours Quotation response only takes 3 hours
1 day Provide production assembly drawings
1 piece MOQ, One piece can also be produced
15-20 working days The production cycle only takes 15-20 working days
real-time Real time synchronization of production progress

BESTSEAL Split Seals

Your Fast-Track Alternative to John Crane Type 3740

Custom Split Seals — From Drawing to Delivery in 15–20 Working Days
