Specifications
Delivery Time :
15 working days
Model Number :
ESD32T
Vessel temperature :
-10…+230°C
Payment Terms :
T/T,Western Union,D/P,D/A,L/C
Seal rings :
Special carbon, silicon Carbide
Certification :
ISO9001
Shaft size :
40…120 mm
MOQ :
1pc
Packaging Details :
Carton
Housing :
Stainless steel
Supply Ability :
1000000/Month
O-rings :
FKM (Viton), EPDM, FFKM (Kalrez, Chemraz, etc.)
Brand Name :
BESTSEAL
Operating pressure :
vacuum…4 bar (abs.)
Place of Origin :
CHINA
Sliding speed :
0...3,5 m/s
Description

EKATO ESD32T Single Acting Dry-Running Mechanical Seal Cartridge Seals


Cartridge Mechanical Seal

Dry-Running Mechanical Seal ESD32T

Function and application

  • Single acting, dry-running mechanical seal for low pressure applications
  • Ready-to-install cartridge unit
  • Deliverable with short heat trap at extremely high temperatures
  • Deliverable with Collector tray prevents abrasion material from contaminating the vessel space

Advantages

  • Leak tightness: minimal leakage from the vessel side
  • Suitable for sealing non-critical substances
  • Plug + seal: no adjustment of the spring pre-tension after installation
  • Easy to monitor and install
  • Dry operation eliminates the need for additional installation or supply of seal liquid
  • Visual wear indicator

Working limits

  • Operating pressure: vacuum ... 4 bar (abs.)
  • Vessel temperature: -10…+230°C
  • Shaft size: 40…120 mm

The EKATO ESD32T is most suitable for

  • Speciality chemicals
  • Formulated consumer products
  • Biofuels and bio refineries
  • Storage tanks

BESTSEAL — Your Reliable Partner for Mechanical Seals

BESTSEAL Advantage:
15 years Focused in mechanical seal manufacturing
3 hours Quotation response only takes 3 hours
1 day Provide production assembly drawings
1 piece MOQ, One piece can also be produced
15-20 working days The production cycle only takes 15-20 working days
real-time Real time synchronization of production progress

BESTSEAL Cartridge Mechanical Seal

Your Fast-Track Alternative to EKATO ESD32T

Custom Cartridge Mechanical Seals — From Drawing to Delivery in 15–20 Working Days
