TB1F-30 Single Cartridge Mechanical Seal for Sulzer AHLSTAR Pumps
TB1F-30 Single Cartridge Mechanical Seal for Sulzer AHLSTAR Pumps
TB1F-30 Single Cartridge Mechanical Seal for Sulzer AHLSTAR Pumps
TB1F-30 Single Cartridge Mechanical Seal for Sulzer AHLSTAR Pumps
TB1F-30 Single Cartridge Mechanical Seal for Sulzer AHLSTAR Pumps
TB1F-30 Single Cartridge Mechanical Seal for Sulzer AHLSTAR Pumps
TB1F-30 Single Cartridge Mechanical Seal for Sulzer AHLSTAR Pumps
TB1F-30 Single Cartridge Mechanical Seal for Sulzer AHLSTAR Pumps
TB1F-30 Single Cartridge Mechanical Seal for Sulzer AHLSTAR Pumps
TB1F-30 Single Cartridge Mechanical Seal for Sulzer AHLSTAR Pumps
Specifications
Delivery Time :
15 working days
Seal faces :
SiC/SiC, C/SiC
Model Number :
TB1F-30
Application :
Suitable for various pump types such as AHLSTAR process pump types A, APP, WPP.
Supply Ability :
1000000/Month
Temperature :
120°C / 284°F with internal flushing, 180°C / 355°F with external flushing
Payment Terms :
T/T,Western Union,D/P,D/A,L/C
Linear Speed :
25 m/s / 82 ft/s
Certification :
ISO9001
Specification :
Inner Diameter: 30 mm
MOQ :
1pc
Packaging Details :
Carton
Pressure :
25 bar / 362 psi
O-rings :
EPDM, FKM
Brand Name :
BESTSEAL
Structure :
Single End
Place of Origin :
CHINA
Model NO. :
TB2P-40
Other parts :
316 stainless steel (EN 1.4401, EN 1.4436), duplex EN 1.4462, super duplex EN 1.4410
Description

TB1F-30 Single Cartridge Mechanical Seal for Sulzer AHLSTAR Pumps

TB1F ready-fitted single mechanical seal

with flushing

Suit Sulzer AHLSTAR Series pumps
TB1F-30
TB1F-40
TB1F-50
TB1F-60
TB1F-80
TB1F-90

Internal recirculation liquids

The seal faces are lubricated by the pumped liquid which is circulated

through a pipe from the discharge pipe into the seal chamber

  • Positive or negative inlet pressure
  • Impeller balancing holes are not required, but can be

Liquids

  • Clean and slightly contaminated liquids
  • Viscous liquids up to 250 cSt
  • Temperature up to 140°C / 248°F depending on seal chamber pressure

External flush liquids

The seal faces are lubricated by external clean flushing liquid led through a

pipe from an external source into the seal chamber

  • Positive or negative inlet pressure
  • Impeller balancing holes are not required, but can be

Liquids

  • Clean and slightly contaminated liquids
  • Viscous liquids up to 4’000 cSt
  • Fibrous slurries up to 8%
  • Non-fibrous slurries up to 70%
  • Liquids containing large solids
  • Temperature up to 140°C / 284°F

BESTSEAL — Your Reliable Partner for Mechanical Seals

BESTSEAL Advantage:
15 years Focused in mechanical seal manufacturing
3 hours Quotation response only takes 3 hours
1 day Provide production assembly drawings
1 piece MOQ, One piece can also be produced
15-20 working days The production cycle only takes 15-20 working days
real-time Real time synchronization of production progress
  • BESTSEAL Cartridge Mechanical Seals
  • Custom Cartridge Mechanical Seals — From Drawing to Delivery in 15–20 Working Days
