Specifications
Brand Name :
Y & G
MOQ :
Negotiation
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
8000MT/Month
Delivery Time :
25-35 days
Packaging Details :
Exporting package/wooden box / per customers’ requirement
Material :
TP304L, TP316L, TP317L, TP321, TP347
Standard :
ASTM A778
Type :
Welded
OD :
75mm~1200mm
Wall Thickness :
1.57~12.7mm
Mark :
As Required
Delivery Status :
Unannealed
Description

ASTM A 778 TP304L TP316L TP317L TP321 TP347 Stainless Steel Welded Pipe

This specification covers straight seam and spiral butt seam welded unannealed austenitic stainless steel tubular products intended for low and moderate temperatures and corrosive service where heat treatment is not necessary for corrosion resistance. The user of this specification should be aware that a minimum amount of testing and examination is required of the basic product. The user requiring additional testing or examination is referred to the supplemental requirements or Ordering Information, or both. Users requiring a tubular product with post-weld heat treatment or with radiographic examination are referred to Specifications A 312, A 358, or A 409 as applicable.

Product Standard: ASTM A778

Main steel grades: TP304L, TP316L, TP317L, TP321, TP347.

Application: It is generally used for applications which involve mild corrosion, high strength, and heat resistance.

Chemical Composition & Mechanical properties:

Grade C Mn P S Si Cr Ni Ti Cb plus Ta N
TP304L ≤0.03 ≤2.00 ≤0.045 ≤0.03 ≤1.00 18.0-20.0 8.0-13.0 ... ... ≤0.10
TP 316L ≤0.03 ≤2.00 ≤0.045 ≤0.03 ≤1.00 16.0-18.0 10.0-14.0 ... ... ≤0.10
TP 317L ≤0.03 ≤2.00 ≤0.045 ≤0.03 ≤1.00 18.0-20.0 11.0-15.0 ... ... ≤0.10
TP 321 ≤0.08 ≤2.00 ≤0.045 ≤0.03 ≤1.00 17.0-19.0 9.0-12.0 ... ... ...
TP 347 ≤0.08 ≤2.00 ≤0.045 ≤0.03 ≤1.00 17.0-19.0 9.0-12.0 ... ... ...

Grade UNS
Designation		 Tensile
Strength, min
(MPa)		 Yield
Strength
min, (MPa)		 Elongation in 2
in. (50 mm)
min, %
TP304L S30403 485 170 40
TP316L S31603 485 170 40
TP317L S31703 515 205 35
TP321 S32100 515 205 40
TP347 S34700 515 205 40

Inspection and Test: chemical composition test, mechanical properties test(tensile, yield, elongation), process properties test(flatting, flaring, bending, hardness, impact, etc.), appearance and size test, non-destructive inspection test, hydrostastic test.

Mark: As required.

Delivery Status: Unannealed

Packing: Exporting package/wooden box /as requirement.
