JIS 3 8 Stainless Steel Tubing 201 202 301 304 304l 321 316 316l S32250
JIS 3 8 Stainless Steel Tubing 201 202 301 304 304l 321 316 316l S32250
JIS 3 8 Stainless Steel Tubing 201 202 301 304 304l 321 316 316l S32250
JIS 3 8 Stainless Steel Tubing 201 202 301 304 304l 321 316 316l S32250
JIS 3 8 Stainless Steel Tubing 201 202 301 304 304l 321 316 316l S32250
JIS 3 8 Stainless Steel Tubing 201 202 301 304 304l 321 316 316l S32250
Specifications
Brand Name :
Y & G
MOQ :
Negotiation
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
8000MT/Month
Delivery Time :
25-35 days
Packaging Details :
Exporting package/wooden box / per customers’ requirement
Standard :
JIS, AiSi, ASTM, GB, DIN, EN
Material :
200 Series/300 Series/400series
Type :
Seamless,Welded
Shape :
Round.square.Rectangle
Technique :
Cold Rolled Hot Rolled
Steel Grade :
300 Series, 301, 316, 304, 201
Certificate :
ISO 9001-2000, SGS
Description

High quality 201 202 301 304 304L 321 316 316L s32250 stainless steel tube

Item
Round aisi tube prices 201 304 304l 316 stainless steel pipe/tube
Steel grade
300 series
Standard
ASTM A213,A312,ASTM A269,ASTM A778,ASTM A789,DIN 17456, DIN17457,DIN 17459,JIS G3459,JIS G3463,GOST9941,EN10216, BS3605,GB13296
Material
304,304L,309S,310S,316,316Ti,317,317L,321,347,347H,304N,316L, 316N,201,202
Surface
Polishing,annealing,pickling,bright
Type
hot rolled and cold rolled
stainless steel round pipe/tube
Size
Wall thickness
1mm-150mm
Outer diameter

6mm-2500mm
Package
Standard export seaworthy package,or as required.
Application
It is widely used in the fields of petroleum, food, chemical industry, construction, electric power, nuclear energy,energy,machinery, biology, papermaking, shipbuilding and boilers. Pipes can also be made according to customer requirements.
Contact
If you have any questions,please feel free to contact me.
Container size
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM

40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM

40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM
Austenitic Stainless Steel
201, 301, 304, 305, 310, 314, 316, 321, 347, 370, etc
Martensitic Stainless Steel
410, 414, 416, 416, 420, 431, 440A, 440B, 440C, etc
Duplex Stainless Steel
S31803, S32101, S32205, S32304, S32750, etc
Ferritic Stainless Steel
429, 430, 433, 434, 435, 436, 439, etc

Chemical component ( %)
Grade ASTM
C
Si
Mn
S
P
Cr
Ni
201
≤0.15
≤0.75
5.50-7.50
≤0.030
≤0.060
16.00-18.00
3.50-5.50
304
≤0.07
≤1.00
≤2.00
≤0.030
≤0.035
17.00-19.00
8.00-11.00
304L
≤0.03
≤1.00
≤2.00
≤0.030
≤0.035
18.00-20.00
8.00-12.00
309S
≤0.08
≤1.00
≤2.00
≤0.030
≤0.035
22.00-24.00
12.00-15.00
310S
≤0.08
≤1.00
≤2.00
≤0.030
≤0.035
24.00-26.00
19.00-22.00
316
≤0.08
≤1.00
≤2.00
≤0.030
≤0.045
16.00-18.00
10.00-14.00
316L
≤0.03
≤1.00
≤2.00
≤0.030
≤0.035
16.00-18.00
12.00-15.00

JIS 3 8 Stainless Steel Tubing 201 202 301 304 304l 321 316 316l S32250
