Burn And Test For 6.6kw Water-cooled Inductive Water Temperature OBC/MCU Power Supply
Burn And Test For 6.6kw Water-cooled Inductive Water Temperature OBC/MCU Power Supply
Burn And Test For 6.6kw Water-cooled Inductive Water Temperature OBC/MCU Power Supply
Burn And Test For 6.6kw Water-cooled Inductive Water Temperature OBC/MCU Power Supply
Burn And Test For 6.6kw Water-cooled Inductive Water Temperature OBC/MCU Power Supply
Burn And Test For 6.6kw Water-cooled Inductive Water Temperature OBC/MCU Power Supply
Specifications
Certification :
CE,ROHS
Cabinet body color :
Grey
Model Number :
CP-OC663001
Purpose :
Aging test of on-board OBC/MCU power supply
Supply Ability :
30sets/month
MOQ :
1
Delivery Time :
30 work days
Payment Terms :
D/P,T/T,L/C
Price :
¥ 88500 yuan
Brand Name :
CPET
Item number :
CPMT-OC6616H
Packaging Details :
Wooden box packaging
Place of Origin :
China
The external dimensions of the aging cabinet :
L2250*W1500*H2100MM
Description
Burn And Test For 6.6kw Water-cooled Inductive Water Temperature OBC/MCU Power Supply
  • The system is composed of 1 control cabinet, 2 aging cabinets and 1 water temperature cabinet. Two three-phase inductor cabinets The control cabinet is equipped with built-in units such as a computer and power distribution The aging cabinet is equipped with temperature control functions, waterways, load zones, product zones and other units The water temperature cabinet has 8 inlets and 8 outlets
Technical parameters
Cabinet structure
Material Cold-rolled sheet
The external dimensions of the aging cabinet L2250*W1500*H2100MM
Dimensions of the electrical control cabinet L860*W880*H2100MM
Dimensions of the water cooler L1200*W1500*H2100MM
Dimensions of three-phase inductor cabinets L1500*W1200*H2100MM
The opening method for the product area Four-page folding glass door
Window mode Full-view tempered double-layer glass door
Aging capacity 16PCS per cabinet; 2 cabinets, 32 pieces
Product area structure
Product area space L1800*W480*H350MM/floor
The number of floors in the product area 4th floor
Floor height 350MM
Aging quantity A single layer can age 4 products (product size no larger than 450*330*250mm)
High-voltage load model CP8803(50-800V/25A/7KW )
Cabinet structure
Cabinet body color Grey
LOGO on the nameplate of the aging cabinet CPET
The entire aging cabinet is zoned It is divided into A and B zones for power control
The position of the three-color light The upper right corner of the cabinet is in yellow, green and red
Bottom casters Universal casters, with a load capacity of 500KG each
The height of the low-level operation 250mm
Top-level assignment height 1450mm
Each floor is equipped with lighting strips
OBC power supply terminal interface Installed on the middle partition AC power supply: single-phase PP75 4P+ three-phase PP75 6P Signal communication terminal 5569 2*8 'P High voltage SB50, low voltage SB350
MCU output terminal Through-type 200A 3P terminal block
Low-voltage load CP8601 (3-60V/240A/3.2KW)
Three-phase inductor 180A air-cooled three-phase inductor (peak 300A for 10 seconds, inductance 0.18mH)
