Specifications
MOQ :
2
Price :
US$135
Brand Name :
Bestone
Model Number :
CM-8820
Certification :
CE,ROHS
Place of Origin :
CHINA
Payment Terms :
T/T,Western Union
Supply Ability :
More than 500pcs per month
Delivery Time :
3-5 working days
Packaging Details :
plastic carrying case and white paper box
Model NO. :
CM-8820
Min. Sample Thickness :
0.3 mm
Accuracy :
± 1~5%N or ± 5 μm
Transport Package :
Box and Carrying Bag
Specification :
161 x 69x 32 mm
Trademark :
BESTONE
Origin :
China
HS Code :
9031809090
Description
Paint Coating Thickness Meter Gauge with F Probe 0~2000μm CM-8820
The CM-8820 coating thickness gauge is a portable measuring instrument designed for fast, accurate, and non-destructive measurement of coating thickness. Suitable for both laboratory environments and harsh field conditions, this versatile instrument accommodates multiple measuring requirements through interchangeable probes. Widely used in manufacturing, metal processing, chemical industries, and quality inspection applications.
CM-8820 Portable Paint Thickness Meter with F Probe 0 2000μm
Measurement Principles & Applications
Principles Applications Examples
F Type
Magnetic Induction (Iron Base)		 Measure thickness of non-magnetic materials on magnetic substrates Galvanizing layer, lacquer layer, porcelain enamel layer, phosphide layer, copper tile, aluminum tile, some alloy tile, paper
NF Type
Eddy Current (Aluminum Base)		 Measure thickness of non-conductive coatings on non-magnetic metals Anodizing, varnish, paint, enamel, plastic coatings, powder coatings on aluminum, brass, non-magnetic stainless steel
Key Features
  • Complies with ISO 2178 standards for laboratory and harsh field conditions
  • Advanced micro-computer LSI circuit and crystal time base for high accuracy and fast measurement
  • Wide measuring range with high resolution capabilities
  • Digital LCD display eliminates reading errors and guesswork
  • Durable, maintenance-free construction with lightweight ABS plastic housing
  • Ergonomic design for comfortable handling in either hand
Technical Specifications
Display 4 digits, 10mm LCD
Principle F Magnetic Induction
Range 0 ~ 2000µm / 0 ~ 80 mil
Resolution 0.1µm (0 ~ 99.9µm)
1µm (over 100µm)
Accuracy ±5%n or 5.0µm
Operating Condition Temperature: 0 ~ 40°C
Humidity: < 80%
Power Supply 4 x 1.5 AA (UM-3) batteries
Size 161 x 69 x 32 mm
Weight Approximately 260 g (including batteries)
Standard Accessories
  • Main Unit x 1pc
  • Probe (F Type) x 1pc
  • Calibration Base Set (F Type) x 1pc
  • Calibration Foils (1 set, 4 pieces)
  • Carrying Case x 1pc
  • Operation Manual x 1pc
