FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
Specifications
MOQ :
2
Price :
negotiable
Brand Name :
Bestone
Model Number :
FM-204-100K
Certification :
CE
Place of Origin :
CHINA
Payment Terms :
T/T,Western Union
Supply Ability :
more than 200pcs per month
Delivery Time :
5-8 working days
Packaging Details :
plastic carrying case and white paper box
Type :
Weight
Display :
Digital
Brand :
Bestone
Applicable Industry :
Electronics
Spring Dynamometer Species :
Spring Dynamometer
Application Area :
Product Manufacturing
Bracket :
Without Bracket
Customized :
Customized
Force Range :
100kgf
Resolution :
0.01kgf
Accuracy :
±0.5%Fs±1digit
Unit :
Kgf, GF, N, Lbf
Measurement State :
Peak Value Measurement, Real Time Measurement
LCD Display :
2 Reversed 4 Digit LCD
Power off :
10 Minutes Auto Power off, Manual Power off
Backlight :
Blue Backlight
Safe Load :
150% Fs ( Buzzer Alarm Over 110% Fs )
Data Output :
USB, Bluetooth
Transport Package :
Box and Carrying Case
Description
Digital Force Gauge FM-204-100K
The Digital Force Gauge FM-204-100K is a precision instrument designed for high-accuracy push and pull force testing. This versatile tool finds applications across multiple industries including electronics, automotive parts, construction hardware, textiles, fire safety equipment, lock manufacturing, and scientific research institutions.
Key Features
  • High accuracy and resolution for precise measurements
  • Digital display eliminates guesswork and reading errors
  • Four selectable measurement units: N, kg, lb, g with easy conversion
  • Peak value hold function for maximum force recording
  • 10-minute auto power off with manual override option
  • Dual power options: alkaline batteries or 5V DC power supply
Technical Specifications
Force Range ±100 kgf
±980 N
±220 Lbf
Resolution 0.01 kgf
0.1 N
0.1 Lbf
Accuracy ±0.5% FS ±1 Digit
Measurement Units kgf, gf, N, Lbf
Measurement States Peak Value Measurement, Real Time Measurement
Display 2 Reversed 4-Digit LCD
Power Management 10 Minutes Auto Power Off, Manual Power Off
Backlight Blue Backlight
Safe Load 150% FS (Buzzer Alarm Over 110% FS)
Power Supply 2x1.5 AA (UM-3) Battery or 6V DC Power Supply
Operating Temperature 0ºC to 40ºC
Operating Humidity Less than 80%
Environmental Requirements No vibration source or corrosive medium
Weight 390g
Dimensions 211mm x 80mm x 36mm
Standard Accessories
Digital Force Gauge, Pulling Hook, Flat Tip, Cone Tip, V-shaped Groove Tip, V-shaped Wedge Tip, Manual, Carrying Case
Optional Accessories
Power adapter
