1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer
1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer
1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer
1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer
1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer
1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer
1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer
1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer
Specifications
Brand Name :
HengShou
Certification :
ISO SGS
Place of Origin :
Sichuan
MOQ :
1
Price :
$19900-39900 Sets
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Sets Years
Delivery Time :
10 Work Days
Product name :
Tomato Continuous Belt Dryer
Temperature :
60-90°c（Customized）
Work time :
Continuous
Product Usage :
Fruit category
Mesh belt layers :
4-8
Type of action :
Flake
Description

Heat Expansion And Cold Shrinkage Resistant To Fracture Tomato Continuous Belt Dryer

Description:

  1. High thermal efficiency: Different airflow modes can be selected according to different materials, maximizing the realization of high-efficiency drying operations under process conditions.
  2. Energy saving: automatic temperature control and automatic dehumidification are used for hot air circulation, reducing heat emission, and the heat utilization rate can reach more than 80%, and the energy saving is remarkable.

Application: asparagus, beans, kidney beans, lentils, eggplant, red pepper, pepper, black fungus, white fungus, papaya slices, yam slices, bitter gourd slices, radish strips, cucumber slices, mushrooms, mushrooms, ginger slices, garlic, etc.

1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer

Specifications:

Model DW2×6m DW2×8m DW2×10m DW2×12m DW2×14m DW2×16m
Area of dry 3 layers 29㎡ 40㎡ 51㎡ 62㎡ 73㎡ 83㎡
4 layers 39㎡ 53㎡ 68㎡ 83㎡ 97㎡ 110㎡
5 layers 48㎡ 66㎡ 85㎡ 103㎡ 121㎡ 138㎡
6layers 57㎡ 79㎡ 102㎡ 124㎡ 145㎡ 165㎡
Thickness of the material 50---150mm
Operation temperature 40---120℃
Drying time 0.5——5 hour or 3——15 hour
Motor power 1.1kw 1.5kw 1.5kw 1.5kw 2.2kw 3kw
Evaporation,capacity 200-400kg/h 300-600kg/h 400-700kg/h 500-800kg/h 600-1000kg/h 700-1200kg/h
Size of hot blast stove 1.2×2.5×1.7 1.2×2.7×1.9 1.3×3×2 1.3×3×3 1.6×3.5×2.2 1.6×3.7×2.2
Fan 8C-15kw 10C-15kw 10C-22kw 10C-37kw 12C-30kw 12C-45kw
Output conveyor 1.1kw
Total power 18kw 18.4kw 26kw 41kw 35.1kw 46.7kw

MATERIAL APPLICATION

1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer

COMPANY PROFILE

1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer

PATENT CERTIFICATE

1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer

SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.

1.1kw Automatic Continuous Belt Dryers Tomato Drying Equipment MultiLayer
