Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control
Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control
Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control
Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control
Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control
Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control
Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control
Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control
Specifications
Brand Name :
HengShou
Certification :
ISO SGS
Place of Origin :
Sichuan
MOQ :
1
Price :
$19900-39900 Sets
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Sets Years
Delivery Time :
10 Work Days
Product name :
Chili Seafood Mesh Belt Dryer
Product Features :
Dehydration
Heating method :
steam heating, hot air heating
Product details :
Strong integration ability
Dimension :
Customized
Total power of equipment :
11.4
Description

Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control

Description:

Pomace Mesh Belt Dryer drying equipment that uses steel mesh as a conveyor belt to carry materials for continuous drying is suitable for flow operation. Since the conveyor belt is in the form of a mesh, it is suitable for drying regular or irregular lumps (such as coal lumps, various mineral powders, food, vegetables, etc.). This machine can be used with other equipment. Can also be used alone.

Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control

Specifications:

Model DW2×6m DW2×8m DW2×10m DW2×12m DW2×14m DW2×16m
Area of dry 3 layers 29㎡ 40㎡ 51㎡ 62㎡ 73㎡ 83㎡
4 layers 39㎡ 53㎡ 68㎡ 83㎡ 97㎡ 110㎡
5 layers 48㎡ 66㎡ 85㎡ 103㎡ 121㎡ 138㎡
6layers 57㎡ 79㎡ 102㎡ 124㎡ 145㎡ 165㎡
Thickness of the material 50---150mm
Operation temperature 40---120℃
Drying time 0.5——5 hour or 3——15 hour
Motor power 1.1kw 1.5kw 1.5kw 1.5kw 2.2kw 3kw
Evaporation,capacity 200-400kg/h 300-600kg/h 400-700kg/h 500-800kg/h 600-1000kg/h 700-1200kg/h
Size of hot blast stove 1.2×2.5×1.7 1.2×2.7×1.9 1.3×3×2 1.3×3×3 1.6×3.5×2.2 1.6×3.7×2.2
Fan 8C-15kw 10C-15kw 10C-22kw 10C-37kw 12C-30kw 12C-45kw
Output conveyor 1.1kw
Total power 18kw 18.4kw 26kw 41kw 35.1kw 46.7kw

MATERIAL APPLICATION

Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control

COMPANY PROFILE

Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control

PATENT CERTIFICATE

Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control

SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.

Vegetables Chili Seafood Mesh Belt Dryer Intelligent Temperature Control
