Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability
Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability
Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability
Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability
Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability
Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability
Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability
Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability
Specifications
Brand Name :
ShouKe
Certification :
ISO SGS
Place of Origin :
Sichuan
MOQ :
1
Price :
$19900-39900 Sets
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Sets Years
Delivery Time :
10 Work Days
Conveyor speed :
0.2 to 2.0m/min
Inlet air temperature :
40-80℃
Heating source :
Electric/gas/steam
Control system :
PLC and touch screen
Humidity range :
10% to 80% RH
Air velocity :
2.0-10.0m/s
Description

Belt Dryer Chili Delicate Products With Low Temperature Drying Capability

Description:

Energy-Efficient Continuous Belt Dryer for Sustainable Chili Processing:

Our energy-efficient continuous belt dryer is designed to help you reduce your carbon footprint and lower your operating costs. With a high-efficiency heating system and advanced heat recovery technology, this drying equipment can help you save up to 50% on energy costs compared to conventional drying methods.

Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability

Specifications:

Model DW2×6m DW2×8m DW2×10m DW2×12m DW2×14m DW2×16m
Area of dry 3 layers 29㎡ 40㎡ 51㎡ 62㎡ 73㎡ 83㎡
4 layers 39㎡ 53㎡ 68㎡ 83㎡ 97㎡ 110㎡
5 layers 48㎡ 66㎡ 85㎡ 103㎡ 121㎡ 138㎡
6layers 57㎡ 79㎡ 102㎡ 124㎡ 145㎡ 165㎡
The thickness of the material 50---150mm
Operation temperature 40---120℃
Drying time 0.5——5 hour or 3——15 hour
Motor power 1.1kw 1.5kw 1.5kw 1.5kw 2.2kw 3kw
Evaporation, capacity 200-400kg/h 300-600kg/h 400-700kg/h 500-800kg/h 600-1000kg/h 700-1200kg/h
Fan 8C-15kw 10C-15kw 10C-22kw 10C-37kw 12C-30kw 12C-45kw
Output conveyor 1.1kw
Total power 18kw 18.4kw 26kw 41kw 35.1kw 46.7kw

MATERIAL APPLICATION

Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability

COMPANY PROFILE

Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability

PATENT CERTIFICATE

Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability

SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.

Delicate Products Belt Chili Dryer Machine With Low Temperature Drying Capability
