Automatic Lamination Stacking Machine Battery Electrode Cells Making
Automatic Lamination Stacking Machine Battery Electrode Cells Making
Specifications
Brand Name :
Honbro
Model Number :
600 Type
Certification :
CE certification
Place of Origin :
Dongguan, China
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
350 sets/year
Delivery Time :
lab machine: 7-8 weeks, Mass production machine: 13-14 weeks
Packaging Details :
Fumigation-free wooden box and vacuum moisture-proof treatment
Separator cut-off and reverse closure time :
≤12S
Dusting mode :
The top of the equipment is equipped with FFU to remove dust
Separator electrostatic removal :
Standard
MES function :
It can dock with MES system
Description

Function Description

  • This deviceis suitable for z-shaped lamination of anode and cathode plates and separator of lithium ion battery cell. The anode is folded first (the same side or the opposite side of anode and cathode ears). After lamination is completed, the separator is heated and side glue is attached
  • Optional configuration: pasting mode can be pasting side glue or flat glue, the end coil separator and the number of end coil coil can be set, the discharge of the cell can butt the whole line conveying line, it can be upgraded to a cutting and folding machine, the end of the cell dust removal after the separator is cut.

Technical Parameters

Item 600type
Electrode location mode CCD Visual positioning
Single piece efficiency 0.5-1S/PCS
Compatible electrode size L450-600mm
L80-150mm
Stacking table structure Air Cylinder pressure claw
Ultrasonic missing Angle detection Standard
Alignment of adjacent electrode ≤±0.3mm
Overall alignment of electrode ≤±0.5mm
Alignment between the electrode and the adjacent separator ≤±0.5mm
Separator cut-off and reverse closure time ≤12S
Dusting mode The top of the equipment is equipped with FFU to remove dust
Separator electrostatic removal Standard
MES function It can dock with MES system
