Cell Lithium Battery Stacking Machine Equipment 5-20mm Thickness
Cell Lithium Battery Stacking Machine Equipment 5-20mm Thickness
Specifications
Brand Name :
Honbro
Model Number :
200 ， 300 Type
Certification :
CE certification
Place of Origin :
Dongguan, China
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
350 sets/year
Delivery Time :
lab machine: 7-8 weeks, Mass production machine: 13-14 weeks
Packaging Details :
Fumigation-free wooden box and vacuum moisture-proof treatment
Compatible with cell thickness :
5-20mm
End loss time :
≤8s
Pole piece positioning mode :
CCD
Alignment of pole sheet to diaphragm :
≤±0.3mm
Description

All Metal Lithium Stacking Machine , 200 , 300 Type , Cells Making

Function Description

This equipment is suitable for lithium ion battery cell, the negative electrode is a zigzagged sheet of all-metal lithium material, the negative electrode is stacked first (the same or different side of the positive and negative ear), after the lamination is completed, the diaphragm is heated, the side glue is attached, and the material is transferred to the stacking platform by mechanical hand, and the material is collected manually

Technical Feature

  • The whole machine adopts KEYENCE bus control, diaphragm unwinding adopts full closed-loop tension control, swing roll tension fluctuation ±1.5N
  • Automatically do not remove the pole ear bending, missing Angle (corner) pole piece
  • It provides a variety of docking methods such as single stacking blanking, bare cell blanking to the whole line pulling belt, automatic cycle of the trough/tray, etc
  • It has four sides blowing, bending, brush, ultrasonic sensor and other anti-heavy film functions
  • It can expand the functions of hot pressing, tail winding, flat adhesive, short circuit test, thickness test and so on
  • FFU vacuum cleaner reduces dust in equipment and improves cell quality

Technical Parameters

Item 200 type 300 type
Compatible pole sheet size

L 50-200mm

M 50-150mm

L 150-300mm

M 80-150mm
Compatible with cell thickness 5-20mm
The efficiency of single chip ≤1s/PCS ≤1.1s/PCS
End loss time ≤8s
Pole piece positioning mode CCD
Alignment of pole sheet to diaphragm ≤±0.3mm
Alignment of adjacent polar plates ≤±0.2mm
Overall alignment of polar plates ≤±0.4mm
Dust removal way The top of the equipment is equipped with FFU, and the internal cleanliness of the equipment can reach 100,000 level after dust removal by light industrial vacuum cleaner
The CCD detects the alignment of the pole plate of the stack option
Qualification rate 99.2%
Action 98%
