Electrode Drying Oven Vacuum Heating Oven 0.1℃ Precision Temperature Control Lab-Specific
Electrode Drying Oven Vacuum Heating Oven 0.1℃ Precision Temperature Control Lab-Specific
Electrode Drying Oven Vacuum Heating Oven 0.1℃ Precision Temperature Control Lab-Specific
Electrode Drying Oven Vacuum Heating Oven 0.1℃ Precision Temperature Control Lab-Specific
Electrode Drying Oven Vacuum Heating Oven 0.1℃ Precision Temperature Control Lab-Specific
Electrode Drying Oven Vacuum Heating Oven 0.1℃ Precision Temperature Control Lab-Specific
Electrode Drying Oven Vacuum Heating Oven 0.1℃ Precision Temperature Control Lab-Specific
Electrode Drying Oven Vacuum Heating Oven 0.1℃ Precision Temperature Control Lab-Specific
Specifications
Brand Name :
ACEY
Model Number :
ACEY-VDO-2
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Price :
USD 1000 /Set
Payment Terms :
T/T,PayPal,L/C,Western Union,MoneyGram
Supply Ability :
200 Sets/Month
Temperature measurement accuracy :
0.1℃
Uniformity :
5℃
Voltage :
single-phase standard AC 220V 50/60HZ
Vacuum :
<133Pa
Warranty :
1 Year Warranty With Lifetime Support
Packaging Details :
Plywood Case
After-sales Service :
24/7 Technical Support
Delivery Time :
7~35 Days
Description

Electrode Drying Oven Vacuum Heating Oven 0.1℃ Precision Temperature Control Lab-Specific



Product Description

ACEY-VDO-2 is suitable for the drying, sterilization and heat treatment of articles in the laboratories of industrial and mining enterprises, universities, research institutes and other units under vacuum conditions.


Product Features

*Observe the items in the working room at a glance.
*Using integrally formed high temperature resistant silicone rubber sealing
ring to ensure high vacuum in the box.
*The inner tank is made of stainless steel, and the surface of the box body is sprayed with high temperature electrostatic to ensure the product is durable.
*Support precise PID control with automatic adjustment.
*Passed radiation protection and anti-theft system.
*Temperature multi-level control, temperature gradient control.
*Tilt heating, pressure keeping, air cooling, all can be set.
*There are two movable stacking racks.

Technical Parameter

Temperature measurement accuracy 0.1℃
Uniformity 5℃ (the temperature difference is between the center and the edge of the cavity)
Temperature Control Temperature multi-level control, temperature gradient control
Process Settings Tilt heating, pressure keeping, air cooling, all can be set
Structure Configuration There are two movable stacking racks
Voltage single-phase standard AC 220V 50/60HZ
Power <1500W max 10A
Inner cavity size 415 mm x 345 mm x 375 mm
Vacuum <133Pa
Dimensions 710mm X 565mm X 555mm
Weight 30kg


Product DisplayElectrode Drying Oven Vacuum Heating Oven 0.1℃ Precision Temperature Control Lab-Specific

Electrode Drying Oven Vacuum Heating Oven 0.1℃ Precision Temperature Control Lab-Specific
