Small Vacuum Heating Cylindrical Battery Film Coating Machine
Small Vacuum Heating Cylindrical Battery Film Coating Machine
Small Vacuum Heating Cylindrical Battery Film Coating Machine
Small Vacuum Heating Cylindrical Battery Film Coating Machine
Specifications
Model Number :
ACEY-HFC260
Price :
USD 3200~3334/Set
Film coating speed :
0～120mm/sec
Vacuum plate size :
L365mm×W200mm×H32mm
Scraper adjustable rang :
0～3.5mm
Power supply :
220V/50Hz
Weight :
49KG
Dimensions :
L505mm×W355mm×H325mm
Brand Name :
ACEY
MOQ :
1 Set
Payment Terms :
T/T,PayPal,L/C,Western Union,MoneyGram
Supply Ability :
200 Sets/Month
Place of Origin :
China
Warranty :
1 Year Warranty With Lifetime Support
Certification :
CE
Packaging Details :
Plywood Case
After-sales Service :
24/7 Technical Support
Delivery Time :
7~35 Days
Description

Small Vacuum Heating Cylindrical Battery Film Coating Machine

Product Description

ACEY-HFC260 film coating machine is dedicated to the continuous coating process of cathode and anode electrode of lithium ion batteries, suitable for small-scale experiments in colleges and enterprises.

Features

*Drying heating, digital display temperature control, working temperature 130℃;
*Digital display timer, drying time can be set freely;
*The coating speed is adjustable within the range of 0～120mm/sec (lithium iron phosphate slurry);
*Vacuum aluminum plate, can quickly place or remove the substrate;
*The stroke can be adjusted by the stroke switch between 0～250mm;
*With a scraper for adjusting the thickness of the coating film (precision 0.01mm);
*Small size, can save space;
*Exquisite appearance, the sheet metal adopts three-dimensional geometric design, which is simple and beautiful;
*The stroke can be adjusted by the stroke switch between 0～250mm;
*Includes 1 oil-free vacuum pump;

Specification

Film coating speed: 0～120mm/sec (lithium iron phosphate paste);
Vacuum plate: aluminum plate with vacuum;
Vacuum plate size: L365mm×W200mm×H32mm;
Scraper adjustable range: 0～3.5mm;
Heating drying system: room temperature～130℃, digital display temperature controller, accuracy ± 1℃
Power supply: 220V/50Hz;
Weight: 49KG;
Dimensions: L505mm×W355mm×H325mm

Product Details

Small Vacuum Heating Cylindrical Battery Film Coating Machine
