Specifications
Brand Name :
YJFIRST
Model Number :
YJ-ES215N
Certification :
CE, ROHS, FCC, IEC, FDA
Place of Origin :
Guangdong, China
MOQ :
1Pcs
Price :
$39
Payment Terms :
T/T
Supply Ability :
20000pcs/month
Delivery Time :
3-7 work days
Packaging Details :
Gift box
Product name :
NFC Barcode Scanner
Feature :
Ultra-thin thickness
Interface :
USB, USB Virtual Serial, TTL
Size :
5.4*3.4*0.9cm
Scan type :
1D/2D/QR Code
Scan Mode :
Automatic
Keywords :
2d Barcode Reader
Style :
Qr Scanner
Description

Access Control Rfid NFC Barcode Scanner Embedded Scanner Module Qr Code Card Reader RS232 Barcode Reader

Product introduction

YJ-ES215 is a 2D cost-effective desktop scanner with advanced CMOS image recognition technology.

It can easily read paper, goods, screens and other media 1D 2D barcodes.

Widely used in kiosk, turnstiles, vending machines, ticket checking machines.

Features

  • Hardware Interfaces: UART, USB, TTL, RS-232 for easy connectivity.

  • Software Support: SDKs/APIs (e.g., Linux/Android drivers) for customization.

  • Ultra-Fast Decoding: Sub-100ms response time for high-speed applications.

  • High Accuracy: Combines high-resolution sensors (e.g., 5MP) with advanced algorithms for low-light performance.

  • Industrial Durability: IP65/IP67 dust/water resistance, shockproof (1.5m+ drops).

Parameter

Capability
Collection method
Image type, CMOS Sensor
Picking rate
1 / 60 Seconds
Field of view Angle
Diagonal is 73°, 61° horizontal, and 48° vertical
Ability to read
Read the way
Close to the approach window, you can move the reading
Scan depth of field *
test condition
depth of field
ITF 18bytes 7.5 mil commodity code
50~130mm
Code 39 4mil 10B
40~100mm
Code 128 14mil 17B (SF number)
85~300mm
QR Code 35mil (WeChat payment code)
25~440mm
Scan the Angle
The angle is 360°, elevation ± 60°, and bias ± 60°
Support code system
In line with the international and domestic general QR code standards:
QR Code, Data Matrix, PDF417, Hanxin, Dotcode, et al
In line with the international and domestic general one-dimensional code standards:
UPC-A, UPC-E, EAN-8, EAN-13, ISBN, Code 128, GS1 128,
ISBT 128, Code 39, Code93,Code 11, Interleaved 2 of 5,
Industrial 2 of 5,Matrix 25, Standard 25, Codabar,
MSI / MSI PLESSEY, GS1 DataBar et al

oggle
Socket interface
12 PIN cable socket, 1.25mm Pitch
12 PIN 0.5 mm Pitch FPC socket
Power supplies are either 3-3.6V or 3.6-6V
USB/3V TTL/5V TTL
Scan pattern
Command mode / induction mode / trigger mode
LED light prompt
Green: Read the code success status
The buzzer tip
Yes
Data line (optional)
USB 2 meters straight line, RS232 2 meters straight line, customizable
External scalable interface
Buzzer, decoding successful prompt lamp, trigger signal
Enviromental parameter
Working temperature
-30℃ ~ 70℃
Storage temperature
-40℃ ~ 80℃
Humidity
Relative humidity: 5% ~ 95% (no condensation)
Ambient light
Max.100,000 Lux
Electrical parameters
Input voltage
3~3.6V or 3.6 to 6 V
Working current
Less than 300 mA (5V input)
Install
Lashing eye
Four 2.3mm diameter fixed hole
FAQ
Q:Can you send sample?
A:Yes, YJFIRST welcomes sample order to test. Please contact us for more details before placing sample order.
Q:Can we have our logo or company name to be printed on the product or package?
A:Yes, printer with logo or company name is acceptable, it will be accomplished by silk printing,please contact us for more details.
Q:What's the shipping way?
A: There are DHL, Fedex, TNT, UPS. We also can ship the goods by your shipping account or other express agent you provided.
Q:What's the payment way?
A:We accept Alibaba online orders, PayPal ,T T, LC, Westem Union , MoneyGram.
Q:How about your product warranty?
A:Our oficiallyy promised warranty time is two years after delivery.
Q:How is your quality control?
A:Professional QC team and testing machine( Engine age testing, wire bending machine, switch life testing, shock resistance testing).
CE, FCC & ROHS certificated.
Q:If I come across any problem during product using, where I can get the support?
A:We support you technically 24h/7. Please send all your questions to us, and we will give the professional, patient, expliantion by email
or call in time.
