XT-CHHD002 Toroidal Coil Winding Machine 220V Fully Automatic Magnetic Ring Butterfly Winding Machine
XT-CHHD002 Toroidal Coil Winding Machine 220V Fully Automatic Magnetic Ring Butterfly Winding Machine
XT-CHHD002 Toroidal Coil Winding Machine 220V Fully Automatic Magnetic Ring Butterfly Winding Machine
XT-CHHD002 Toroidal Coil Winding Machine 220V Fully Automatic Magnetic Ring Butterfly Winding Machine
XT-CHHD002 Toroidal Coil Winding Machine 220V Fully Automatic Magnetic Ring Butterfly Winding Machine
XT-CHHD002 Toroidal Coil Winding Machine 220V Fully Automatic Magnetic Ring Butterfly Winding Machine
XT-CHHD002 Toroidal Coil Winding Machine 220V Fully Automatic Magnetic Ring Butterfly Winding Machine
XT-CHHD002 Toroidal Coil Winding Machine 220V Fully Automatic Magnetic Ring Butterfly Winding Machine
XT-CHHD002 Toroidal Coil Winding Machine 220V Fully Automatic Magnetic Ring Butterfly Winding Machine
XT-CHHD002 Toroidal Coil Winding Machine 220V Fully Automatic Magnetic Ring Butterfly Winding Machine
Specifications
Place of Origin :
China
MOQ :
1
Wire Diameter :
0.4-1.8mm
Wire Length :
500-2800mm
Wire Drawing Speed :
0.8-2.5S
Outer Diameter :
13-50mm
Power Supply :
220V±10% 50Hz
Air Pressure :
>0.6Mpa
Device Dimensions :
1630×1980×2050mm
Features :
Fully Automatic, Single/Double Wire, Multilateral Winding
Efficiency :
30% Higher Than Standard Models
Application :
Automotive Electronics, Medical Equipment, Home Appliances
Winding Types :
Single/Double Wire, Common-mode, Multilateral
Description
XT-CHHD002 Toroidal Coil Winding Machine 220V Fully Automatic Magnetic Ring Butterfly Winding Machine
Product Overview
This XT-CHHD002 Fully Automatic Magnetic Ring Butterfly Winding Machine is engineered for high-efficiency production of magnetic ring coils. It delivers 30% improved operational efficiency and is capable of handling diverse winding requirements, including special wires, thick wires, single/double-wire configurations, common-mode, and multilateral winding applications.
Key Features
  • 30% higher efficiency compared to standard models
  • Handles wire diameters from 0.4-1.8mm
  • Supports single/double-wire, common-mode, and multilateral winding
  • Fully automatic operation reduces manual labor requirements
  • Versatile for automotive, medical, and home appliance applications
Technical Specifications
Parameter Value
Product Name Fully automatic magnetic ring butterfly winding machine
Model XT-CHHD002
Wire Diameter 0.4-1.8mm
Wire Length 500-2800mm
Wire Drawing Speed 0.8-2.5S
Outer Diameter 13-50mm
Power Supply 220V±10% 50Hz
Air Pressure >0.6Mpa
Device Dimensions (L)1630×(W)1980×(H)2050mm
Applications
Ideal for producing magnetic ring coils used in:
  • Automotive electronics
  • Medical equipment power supplies
  • Home appliance power supplies
  • Common-mode inductors and various magnetic ring products
Customization & Certifications
Brand: XINGTE
MOQ: 1 unit
Certifications: CE, ISO9001, KC, ISO45001, ISO24001
Origin: China
Frequently Asked Questions
What is the model number?
XT-CHHD002
What is the main advantage?
30% efficiency improvement over traditional machines
What is the wire diameter range?
0.4-1.8mm
