XT-CH001S Fully Automatic Magnetic Ring Winding Machine For Medical Equipment
Product Overview

The XT-CH001S is a high-efficiency, fully automatic toroidal winding machine designed for mass production of magnetic ring coils. It delivers a 30% improvement in efficiency compared to traditional equipment, making it ideal for high-volume manufacturing of common-mode inductors, automotive electronics coils, and power supply components.

It supports thick wire, single/double wire, and multi-sided winding, with stable performance to ensure consistent coil quality. The fully automated process significantly reduces manual labor and error rates, while the servo-driven system guarantees precise winding tension and neat wire arrangement.

Key Features
  • 30% efficiency improvement over traditional winding machines
  • Supports thick wire, single/double wire, and multi-sided winding
  • Fully automatic operation reduces manual intervention
  • High compatibility with various toroidal core sizes
  • Stable and consistent winding quality with low defect rates
  • Certified with CE, ROHS, KC, ISO9001, ISO45001, ISO14001, ISO56005, IATF16949
Technical Specifications
Product Name XT-CH001S Fully Automatic Magnetic Ring Winding Machine
Model XT-CH001S
Wire Diameter 0.5-2.2mm
Wire Length 500-1600mm
Wire Drawing Speed 0.8-2.5S
Outer Diameter of Core 15-50mm
Minimum Inner Diameter After Completion 0.5mm (core inner diameter ≥ 8mm)
Power Supply 220V ±10%, 50Hz
Air Pressure >0.6MPa
Device Dimensions (L)1000 × (W)1700 × (H)2100mm
Applications
  • Automotive electronics
  • Medical equipment power supplies
  • Home appliance power supplies
  • Common-mode inductors and magnetic ring products
  • Power inductors and filter coils
Product Specifications
Brand Name: XINGTE
Model Number: XT-CH001S
Place of Origin: China
Certification: CE, ROHS, KC, ISO9001, ISO45001, ISO14001, ISO56005, IATF16949
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wooden case
Delivery Time: 15-35 days
Payment Terms: LC, T/T
Supply Ability: 2000PCS/Month
Frequently Asked Questions
Q: What is the efficiency improvement of this machine?
A: It provides a 30% efficiency improvement over traditional winding machines.
Q: What types of winding does it support?
A: It supports thick wire, single wire, double wire, common-mode, and multi-sided winding.
Q: What is the maximum applicable wire diameter?
A: The maximum applicable wire diameter is 2.2mm.
