80GHz IP65 Waterproof Millimeter Wave Radar Sensor with 0.3-6m Detection Range for Barrier Gate Vehicle Detection
80GHz IP65 Waterproof Millimeter Wave Radar Sensor with 0.3-6m Detection Range for Barrier Gate Vehicle Detection
80GHz IP65 Waterproof Millimeter Wave Radar Sensor with 0.3-6m Detection Range for Barrier Gate Vehicle Detection
80GHz IP65 Waterproof Millimeter Wave Radar Sensor with 0.3-6m Detection Range for Barrier Gate Vehicle Detection
Specifications
Brand Name :
SINOMATIC
Model Number :
TZ7-033
Certification :
CE
Place of Origin :
Shenzhen, China.
MOQ :
Sample order accepted
Price :
US$40~US$60
Payment Terms :
T/T,Western Union,,credit card/Cash/Alipay,L/C,D/A,D/P
Supply Ability :
10,000 pcs per month
Delivery Time :
3-7 working days
Packaging Details :
Carton
Working Voltage（V） :
DC12V
Working Temperature(℃) :
-40 ℃~ +85 ℃
Waterproof Level :
IP65
Frequency（GHz） :
80
Vertical Length (m) :
0.3~6m
Output signal :
Relay
Boom type :
Universal
Debugging methods :
Mobile Bluetooth
Description
79G 80G 81G Road Gate Anti-Smash License Plate Identification Millimeter Wave Radar Detector Sensor Parking System
An 80GHz millimeter-wave radar sensor for vehicle barrier gates provides high-precision, non-contact detection (0.3-6m range) for anti-smashing and automatic gate lifting. Operating in the 79-81GHz range, these sensors feature IP66 protection, ±45° horizontal beam width, and work well in various weather conditions.
Important Usage Precautions
Please read carefully before installation and use:
  • In logistics park trailer scenarios, install one radar above and below to ensure complete vehicle detection coverage and eliminate blind spots
  • Radar installation should not be level with the pole. For cars: install 65cm-75cm from radar bottom to driving surface. For trailers: install 100cm-110cm from radar bottom to driving surface
  • If radar's front is obstructed by license plate recognition systems or other objects, install on a separate pole to avoid interference
  • Not recommended for areas with extensive ground covers or large metal plates. Small area covers or tracks may be used (consult manufacturer's technical staff)
  • Not recommended for sharp turn scenarios or mixed pedestrian/vehicle roads as pedestrians can interfere with detection
  • In simultaneous vehicle entry/exit scenarios, each vehicle requires a dedicated pole; avoid following vehicles or lingering under the arm
  • For advertisement arms, barrier arms, or fold arms, optimal installation faces incoming vehicle direction. If not possible, use dedicated poles per vehicle and avoid lingering under arm
  • Do not power radar using 12V output from barrier gate motherboard; requires independent 12V 1A~2A power supply
Installation Instructions
The radar indicator light should be facing upward and installed vertically on the barrier box.
  • Installation height for cars: 65cm-75cm from radar bottom to ground
  • Installation height for large vehicles: 100cm-110cm from radar bottom to ground
  • Distance between radar and barrier arm: 20cm
80GHz IP65 Waterproof Millimeter Wave Radar Sensor with 0.3-6m Detection Range for Barrier Gate Vehicle Detection
Technical Specifications
Detection Method 80G Millimeter Wave Radar
Response Time 100 ms
Ambient Temperature -40℃ to +85℃
Working Voltage 12V DC
Arm Type Universal
Output Signal Relay
Detection Range 0.3 to 6 meters
Detection Target Vehicle/Pedestrian
80GHz IP65 Waterproof Millimeter Wave Radar Sensor with 0.3-6m Detection Range for Barrier Gate Vehicle Detection
