Single Channel Inductive Loop Detector with 20 kHz to 170 kHz Frequency and Automatic Calibration for Vehicle Detection
Single Channel Inductive Loop Detector with 20 kHz to 170 kHz Frequency and Automatic Calibration for Vehicle Detection
Single Channel Inductive Loop Detector with 20 kHz to 170 kHz Frequency and Automatic Calibration for Vehicle Detection
Single Channel Inductive Loop Detector with 20 kHz to 170 kHz Frequency and Automatic Calibration for Vehicle Detection
Specifications
Model Number :
TLD-110
Frequency range :
20 kHz to 170 kHz
MOQ :
Sample order accepted
Delivery Time :
2-5 working days after payment received
Dimension :
78*40*116mm
Category :
Loop detector
Payment Terms :
T/T,L/C,D/A,D/P,Western Union
Sensitivity :
Three levels of adjustable
Package :
Carton
Certification :
CE/ ISO
Reaction time :
100ms
Place of Origin :
Shenzhen, China.
Output relays :
240V/5A
Supply Ability :
30, 000 pcs per month
Application :
Traffic Monitoring, Parking Management
Rated Current :
250mA
Price :
negotiable
Output method :
Relay
Brand Name :
SINOMATIC
Operating temperature :
-20°C to +65°C
Packaging Details :
Carton
Color Of Shell :
Red
Description
Single Inductive Vehicle Loop Detector Circuit Ground Sensor for Parking Boom Barrier Gate Access Control
The TLD-110 is a single channel inductive loop detector. The principle is based on detecting changes in inductance within the loop caused by the metallic components of passing vehicles. These changes are picked up and evaluated by a microprocessor. Ease of use is ensured through automatic calibration when operating voltage is applied.
Application Scope
  • Parking lot entrance vehicle detection systems
  • Parking space information acquisition systems
  • Electronic traffic light snapshot systems
  • Traffic monitoring and control systems
Features & Functions
Utilizes microprocessor technology to evaluate inductance changes within detection loops. Features include automatic calibration when operating voltage is applied, ensuring ease of use and reliable performance.
Technical Specifications
Model TLD-110
Loop Channel Single
Input Power AC 80V ~ 240V
Rated Power 4.5 W
Output Relay 240V / 5A
Operating Temperature -20°C ~ 65°C
Work Frequency 20 ~ 170 kHz
Reaction Time 10 ms
Sensitivity 3 Levels
Input Interface Digital Signal Input
Product Dimensions 75×37×110 mm (L×W×H)
Loop Connection Wiring Maximum length 20 meters
Single Channel Inductive Loop Detector with 20 kHz to 170 kHz Frequency and Automatic Calibration for Vehicle Detection Single Channel Inductive Loop Detector with 20 kHz to 170 kHz Frequency and Automatic Calibration for Vehicle Detection
Additional Technical Details
  1. Supply voltage AC: 220V, 110V, 24V, 12V
  2. Supply voltage DC: 24V, 12V
  3. Sensitivity: adjustable in 3 increments (high, medium, low)
  4. Operating temperature: -20°C to +70°C
  5. Storage temperature: -40°C to +85°C
  6. Frequency range: 20 kHz to 170 kHz
  7. Reaction time: 100ms
  8. Loop inductance: Ideal: 80μH to 300μH (including connection wiring): Maximum: 50μH to 500μH
  9. Loop connection: <5m optimal
  10. Loop connection wiring: Maximum length 200 meters
  11. Twisted at least 20 times per meter
  12. Dimensions: 74×36×85 mm (W×H×L)
  13. Net Weight: 300g
Company Advantages
  • Low MOQ: Samples available for quality verification
  • High Quality: Ensures market reputation and repeat orders
  • Professional Service: Comprehensive pre-sale and after-sale support
  • Competitive Pricing
  • Fast & Cost-Effective Delivery
  • OEM Services Welcome
