Specifications
Brand Name :
WeSeW
Model Number :
RG-717
Certification :
CE/UL
Place of Origin :
china
MOQ :
1 pc
Price :
Price Negotiation
Payment Terms :
T/T,Western Union
Supply Ability :
10,000 pieces per month
Delivery Time :
10-20 working day
Packaging Details :
Wooden Case
Rotation Direction :
Clockwise/Counterclockwise
Screw Type :
Helicoid or sectional
Strength :
High tensile strength
Usage :
Conveyor
Inclination Angle :
0-45 degrees
Features :
Flexible design, easy to clean
Description

Custom Mixing Reactors 500L–100,000L Stainless Steel Chemical Reaction Vessels Suitable for mixing and dissolving solid-liquid materials in coatings/pigments/dispersions

type
Reaction Kettle
voltage
110V 220V 230V or customized
capacity
500L-10000L
automatic grade
Automatic
power(w)
11
core components
PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump
Warranty
1 Year
dimension(l*w*h)
Customized
Product name
10000L mixing reaction kettle
Application
paint, coating, inks, pigment
Heating method
Oil Heating
Usage
Mixing Paste Proucts
Color
Customized Color
After-sales Service Provided
Video Technical Support
Mixing Type
Frame Mixer
Stirring speed(rpm)
1450 rmp
Hieght of kettle
2820mm
diamater
2200mm



Application area:

It is applied in coating, agrochemical, printing ink ec chemical industries for mixing, dissloving and dispersing liquid and
solid-liqud materials.

Characteristics

- Few air in and remain during dispersing and excellent mixing and adjusting result. Can quickly dissolving material, smaller
particles in middle or high speed mixing.
- According to different requirements; dispersing kettle can be made in different forms: vacuum, normal pressure,
pressure, cooling, heating etc to fulfill diverse processing techniques.
Type
Capacity
L
Power
kW
Disc diameter
mm
Speed
rpm
Diameter
mm
Height
mm
FDK0.5
500
7.5
250
0-1450
800
1000
FDK1
1000
15
300
0-1450
1000
1250
FDK2
2000
30
350
0-1450
1400
1540
FDK3
3000
37
400
0-1450
1500
1880
FDK4
4000
45
450
0-1450
1600
2180
FDK5
5000
55
480
0-1200
1800
2235
FDK6
6000
75
500
0-1200
1900
2360
FDK8
8000
90
550
0-1000
2000
2720
FDK10
10000
110
600
0-1000
2200
2820
