Automatic Stainless Steel Spot Laser Welding Machine Robot Hand Master Cutting Cleaning 3 In 1 2000w
Automatic Stainless Steel Spot Laser Welding Machine Robot Hand Master Cutting Cleaning 3 In 1 2000w
Automatic Stainless Steel Spot Laser Welding Machine Robot Hand Master Cutting Cleaning 3 In 1 2000w
Automatic Stainless Steel Spot Laser Welding Machine Robot Hand Master Cutting Cleaning 3 In 1 2000w
Automatic Stainless Steel Spot Laser Welding Machine Robot Hand Master Cutting Cleaning 3 In 1 2000w
Automatic Stainless Steel Spot Laser Welding Machine Robot Hand Master Cutting Cleaning 3 In 1 2000w
Automatic Stainless Steel Spot Laser Welding Machine Robot Hand Master Cutting Cleaning 3 In 1 2000w
Automatic Stainless Steel Spot Laser Welding Machine Robot Hand Master Cutting Cleaning 3 In 1 2000w
Automatic Stainless Steel Spot Laser Welding Machine Robot Hand Master Cutting Cleaning 3 In 1 2000w
Automatic Stainless Steel Spot Laser Welding Machine Robot Hand Master Cutting Cleaning 3 In 1 2000w
Automatic Stainless Steel Spot Laser Welding Machine Robot Hand Master Cutting Cleaning 3 In 1 2000w
Automatic Stainless Steel Spot Laser Welding Machine Robot Hand Master Cutting Cleaning 3 In 1 2000w
Specifications
Brand Name :
YOUNGYOU
Model Number :
KR1000W KR1500w KR2000W
Certification :
CE
Place of Origin :
CHINA
MOQ :
2
Price :
35000
Payment Terms :
L/C, T/T
Supply Ability :
20sets/month
Delivery Time :
6-8 WEEKS
Packaging Details :
Foam fixation+bubble film protection+wooden box
Warranty of core components :
1 Year
Dimensions :
960x610x1100mm
Wavelength :
1064nm
Max. Output Power :
4.5kw
Single Pulse Energy :
80-120J
Focal Spot Diameter :
0.1-2mm
Weight (KG) :
220 KG
Key Selling Points :
High-accuracy
Description

Robot hand master metal fiber Laser welder spot welding cutting and cleaning machine 3 in 1 2000w

Product Advantage
1.The red light assists in positioning, and the welding position is accurate without deviation.
2.Simple and easy to understand optimization control page, supporting English, Russian, Spanish, Italian, Turkish and other languages.
3.It is easy to learn. A simple training of ten minutes can basically master the welding technology of the machine.
4.The weld is beautiful without deformation, and the post-processing is easier.
5.It saves labor and is 5-10 times faster than argon arc welding.
6.The circuit signal feedback does not give light when the gun is lifted out of operation.
7.Long service life, theoretical service life up to 100000 hours, maintenance free.

About the company

Our guide rail has cooperated with many international well-known robot brands, such as ABB KUKA FANUC Yaskawa UR. The companies involved mainly include palletizing, loading and unloading. The load of the guide rail ranges from 500kg to 5000kg. The length of the guide rail is customized according to the needs of customers. We have made a case that an ABB IRB6700 robot corresponds to 20 CNC machines, and a 50m long guide rail completes the reciprocating motion, loading and unloading of the robot. The number of robots is greatly reduced and the integration cost is saved.


Our company also offers industrial robots at very favorable prices to place orders together at lower prices.
Welcome to Shanghai, China, to investigate our robots and rails!


Company Product Supply
ABB robot
KUKA robot
Yaskawa robot
Fanuc robot
UR robot
Cobot
Guide rail
Cobot made in China


Product specifications

Model:
KR1000W
KR1500W
KR2000W
Operating Model:
Continuous/Modulation
Laser Wavelength:
1080+-5nm
Fiber Cable length:
10M/15M
Laser pulse Frequency:
50kHz-5000KHZ
Welding Thickness Range:
0.5-8mm metallic material
Welding Line Requirements:
≤0.5mm
Welding Speed:
0-120mm/s
Voltage:
220V
220V
380V
Machine power:
≤3KW
≤4KW
≤4.8KW
Working Environment Humidity Range:
<70% No Condensation
Operating Environment Temperature Range:
15-35℃
Machine size:
96x61x110cm
96x61x110cm
117X61X124cm
Machine weight:
210kgs
210kgs
230kgs

Product parameters table

Intelligent operation interface.
You can set parameters such as laser power, gas blowing, welding and swing.
Famous brand laser
Stable performance and long service life of fiber laser generator
Hand held laser welding gun
Flexible welding direction, equipped with automatic wire feeder structure
No damage to the workpiece The welding heat affected area is small, which will not lead to deformation, blackening and other problems of the workpiece
Large welding depth There is no depression at the junction between the convex part of molten material in the molten pool and the matrix
