Specifications
Payment Terms :
T/T
Weight: :
Approximately 580g (including Battery and Antenna)
Model Number :
ZY03
Frequency range： :
100MHz〜8GHz
Certification :
CE
Detection radius :
≥ 1km (The detection range of drones may vary across different frequency bands and transmission power levels. Replacing with a high-gain directional antenna can extend the detection range)
MOQ :
1~99
Delivery Time :
5-8 Days
Operating time: :
7H
Price :
980~999
Dimensions: :
164mm × 44mm × 68mm (
Supply Ability :
5000
Video Capture: :
100MHZ-8000MHz Analog Image Transmission
Brand Name :
Roviyno
Product Name: :
Ultra-Wideband Handheld Drone Locator
Packaging Details :
Carton
Place of Origin :
China
Battery capacity: :
2900mAh
Description
Handheld Portable Fpv Uav Detection Defense System Signal Drone Detector
Product Introduction

The portable UAV detector adopts a low-power design and highly integrated design, and is capable of detecting mainstream rotary wing drones such as DJI and AUTEL that use OFDM high-definition image transmission, as well as various DIY crossings that use analog image transmission signals. The device adopts dual antennas and multi-channel simultaneous scanning, which has the characteristics of fast detection speed, high detection sensitivity, long detection distance, low false alarm rate, strong scalability, and easy use.

Technical Specifications
Item Technical Parameters
Receiving Frequency Range 300 MHz–6.2 GHz
Signal Identification OFDM high-definition digital video transmission signals; FM analog FPV video transmission signals
Detection Range ≥1 km
Detection Sensitivity ≤ −96 dBm
Alarm Methods Audible, visual and headset alarms
Alarm Log Capacity ≥500 alarm records
Upgrade & Data Export Interface Micro-USB
Power Supply Removable lithium-ion battery; USB Type-C charging
Battery Capacity 2,400 mAh
Battery Life ≥6 hours (with one battery)
Dimensions ≤135 × 60 × 35 mm (host, antenna excluded)
Weight ≤500 g (including one battery)
