Portable Wideband UAV Drone Detector | 100 MHz–8 GHz RF Detection
Portable Wideband UAV Drone Detector | 100 MHz–8 GHz RF Detection
Portable Wideband UAV Drone Detector | 100 MHz–8 GHz RF Detection
Portable Wideband UAV Drone Detector | 100 MHz–8 GHz RF Detection
Portable Wideband UAV Drone Detector | 100 MHz–8 GHz RF Detection
Portable Wideband UAV Drone Detector | 100 MHz–8 GHz RF Detection
Portable Wideband UAV Drone Detector | 100 MHz–8 GHz RF Detection
Portable Wideband UAV Drone Detector | 100 MHz–8 GHz RF Detection
Specifications
Payment Terms :
T/T
Battery Capacity :
2,900 mAh
Model Number :
ZY03
Video Capture / Demodulation :
100 MHz–8 GHz analog FPV video transmission
MOQ :
1~99
Delivery Time :
5-8 Days
Alarm Methods :
Vibration and audible alarm
Protection Rating :
IP54
Price :
$999-$1200
Log Recording :
Built-in storage for detection and alarm records
Certification :
CE
Signal Identification :
OFDM high-definition digital video transmission signals; FM analog FPV video transmission signals
Supply Ability :
5000
Battery Life :
Approximately 7 hours with a single battery
Brand Name :
Roviyno
Receiving Frequency Range :
100 MHz–8 GHz
Packaging Details :
Carton
Weight :
Approx. 580 g
Place of Origin :
China
Detection Range :
≥1 km
Description
Portable Wideband UAV Drone Detector | 100 MHz–8 GHz RF Detection
Product Description
  • 100 MHz–8 GHz Wideband Detection
    Wide frequency coverage for detecting a broad range of drone and FPV transmission signals.
  • Digital & Analog FPV Detection
    Supports OFDM high-definition digital video transmission and FM analog FPV signals.
  • ≥1 km Detection Range
    Provides reliable detection performance, with extended range available through a high-gain directional antenna.
  • Approx. 7 Hours Battery Life
    Removable 2,900 mAh battery supports extended field operation.
  • Compact & Lightweight
    Only approximately 580 g including battery and antenna, making it suitable for portable deployment.
  • IP54 Rugged Design
    Designed for reliable operation in demanding outdoor environments.
Item Technical Parameters
Receiving Frequency Range 100 MHz–8 GHz
Video Capture / Demodulation 100 MHz–8 GHz analog FPV video transmission
Signal Identification OFDM high-definition digital video transmission signals; FM analog FPV video transmission signals
Detection Range ≥1 km (actual detection range may vary depending on frequency band and UAV transmission power; a high-gain directional antenna can be used for extended detection range)
Alarm Methods Vibration and audible alarm
Log Recording Built-in storage for detection and alarm records
Upgrade & Data Export Interface Dedicated magnetic charging/data cable
Power-On Method Press and hold the power button for 3 seconds
Power Supply Removable lithium battery with USB Type-C charging
Battery Capacity 2,900 mAh
Battery Life Approximately 7 hours with a single battery
Controls Physical buttons; supports volume adjustment, screen backlight control and UAV detection operation
Operating Temperature −20°C to +60°C
Storage Temperature −40°C to +85°C
Protection Rating IP54
Dimensions Approx. 164 × 44 × 68 mm (host, antenna excluded)
Weight Approx. 580 g (including battery and antenna)


Portable Wideband UAV Drone Detector | 100 MHz–8 GHz RF Detection

Typical Applications:

  • Large-scale sporting events and concerts
  • Airports and aviation facilities
  • Industrial parks and energy facilities
  • Government and critical infrastructure
  • Border and coastal security
  • VIP events and temporary security operations
  • Mobile counter-UAS patrols and rapid deployment
