Handheld Design FPV Drone Detector UAV Locator With Frequency Range 600 MHz- 6 GHz
Handheld Design FPV Drone Detector UAV Locator With Frequency Range 600 MHz- 6 GHz
Specifications
Payment Terms :
T/T
Weight: :
650g
Model Number :
H2L pro
Working frequency :
100-900MHz,1.1GHz,1.2GHz,1.4GHz,2.4GHz,5.2GHz,5.8GHz
MOQ :
1~99
Delivery Time :
5-8 Days
Battery Life :
4h
Price :
$1,999~$2,200
Dimensions: :
185mm*80mm*33mm
Certification :
CE
Detection range :
3KM
Supply Ability :
<500 pcs 30 working days
Work temperature: :
-20℃ - 55℃
Brand Name :
Roviyno
Drone models supported :
DJI series drones, FPVs, Xiaomi, Yuneec, Hubsan, Hubson, Powervision, Tello drones etc.
Packaging Details :
Carton
Place of Origin :
China
Locating Module: :
DJI (Phantom and Mavic)
Description
FPV Drone Detector and UAV Locator with Frequency Range 600 MHz- 6 GHz
Functions
  1. Drone positioning: Locates the drones and shows the results as icons of drones on the e-map.
  2. Pilot positioning: Locates the remote controllers (pilots), and shows the results as icons of the remote controllers on the e-map.
  3. FPV detection: capable of detecting and identifying homemade racing drones, real-time analysis of their first-person flight footage.
  4. Pilot navigation: PL2 Pro plans the route for tracking drone controllers with easy operation.
  5. RID detection: PL2 Pro is able to identify DJI drones (with OcuSync protocol), drones with RID, and the unique serial number (SN) of WIFI drones.
  6. Comprehensive information: Realtime display of the drone model, coordinates, velocity, altitude, pilot coordinates and so on.
  7. Black and white list: Once a white list is set, the alarm of PL2 Pro will not be set off if the drone in white list is detected.
  8. Early warning: The device will alarm by beeping or vibrating when detects the drone.
  9. Trajectory playback: Assists security personnel to analyze historical drone flight data.
  10. History records: The detection results will be saved for review, including SN, model, frequency band, etc.
  11. Multiple languages: Supports English, Chinese, Russian, and Portuguese.
Specifications:
Performance Index
NO Indicator Parameter Notes
1 Frequency range 100MHz～6GHz
2 Detection radius 1~2km (urban environment)
2~3km (open environment)
3 Response time 3 ~ 5s
4 Targeting range 1~2km (urban environment)
2~3km (open environment)
5 Detection quantity ≥10
Mechanical Parameters
NO Indicator Parameter Notes
1 Dimensions 185mm*80mm*33mm
2 Weight (658±10)g With an antenna
3 Packing box size L*W*H:(335*260*130mm)±5mm
4 Packing box weight (full) 2.5kg
Electrical Characteristics
NO Indicator Parameter Notes
1 Battery capacity 8000mAh Built-in lithium battery
2 Operating time ～4h When Screen brightness is 20%, temperature is 25℃
3 Charging duration ~2.5 h With the original charger
Environmental Adaptability
NO Indicator Parameter Notes
1 Operating temperature -35~50℃
2 Storage temperature -40~40℃
Touch Screen
NO Indicator Parameter Notes
1 Screen size 6-inch
2 Screen resolution 2160*1080 pixels

System Storage

NO Indicator Parameter Notes
1 Memory 8GB
2 Storage 256GB
Operating Environment
NO Indicator Parameter Notes
1 Operating system Android 12
2 Network environment Online / Offline

Handheld Design FPV Drone Detector UAV Locator With Frequency Range 600 MHz- 6 GHz
