Aluminum Shell RF Signal Block Amplifier Module 4–8 GHz 50W Anti Drone 28V Customized
Aluminum Shell RF Signal Block Amplifier Module 4–8 GHz 50W Anti Drone 28V Customized
Aluminum Shell RF Signal Block Amplifier Module 4–8 GHz 50W Anti Drone 28V Customized
Aluminum Shell RF Signal Block Amplifier Module 4–8 GHz 50W Anti Drone 28V Customized
Aluminum Shell RF Signal Block Amplifier Module 4–8 GHz 50W Anti Drone 28V Customized
Aluminum Shell RF Signal Block Amplifier Module 4–8 GHz 50W Anti Drone 28V Customized
Aluminum Shell RF Signal Block Amplifier Module 4–8 GHz 50W Anti Drone 28V Customized
Aluminum Shell RF Signal Block Amplifier Module 4–8 GHz 50W Anti Drone 28V Customized
Specifications
Supply Ability :
<500 pcs 10 working days
Model Number :
RAH
Working Voltage :
28V
Price :
$1,290-$1,380
Packaging Details :
Carton box
Dimension :
150 × 80 × 2mm
Payment Terms :
T/T
Working Temperature :
-20～+65℃
Place of Origin :
China Mainland
Output Power (Max) :
≥47 dBm
Delivery Time :
7-10 working days
Brand Name :
Roviyno
Frequency Range :
Customized
MOQ :
100
LED indicator :
Yes
Description
4000-8000 MHz 50W Anti-Drone RF Amplifier Module

How does the signal jammer module work?

First, we must detect the target frequency bands. This includes WIFI, GPS and cellular frequencies.

Then, the jamming unit will emit higher-power signals to match or overlap with the target signals.

Finally, the target devices will cease to function.

Components of Signal Jammer Modules

1. Anti-Drone Antennas: They include both omnidirectional and directional antennas, which emit targeted jamming signals to effectively block the frequencies used by unauthorized drones.

2. Signal Generator: It creates jamming signals that interfere with the target signal.

3. Power Amplifier: Amplifies signal generated by signal generator so that it is strong enough for blocking the target signals.

4. Control circuit: This circuit allows the operator to configure settings and monitor performance.

Aluminum Shell RF Signal Block Amplifier Module 4–8 GHz 50W Anti Drone 28V CustomizedAluminum Shell RF Signal Block Amplifier Module 4–8 GHz 50W Anti Drone 28V CustomizedAluminum Shell RF Signal Block Amplifier Module 4–8 GHz 50W Anti Drone 28V Customized
50W Module Technical Datasheet
RF DATA
Item Spec. Remarks
Working Voltage 28V 24-28V
Working current ≤ 4.2A Output 50W
Analog sweeping speed 120 KHz/ 8μ/s Customize
Output Power (Max) 47±1 dBm 50W
Gain 47±1 dB
Ripple in Band ≤ 3 dB Peak
Bandwidth adjustment Yes By screw
Center adjustment Yes By screw
VSWR Protection Internal circulattor Customize
Temperature Protection 75℃ Customize
No-load Protection Yes Customize
Enable control Customize 3-28V
Input Signal Source Built-in high-speed noise modulation signal source
Output VSWR ≤2
High Low Temperature test Temperature -20～+65℃ Working properly
Gain Stability ±2 dB At -20℃～+65℃
Power stability ±2 dB At -20℃～+65℃
Power supply Port Positive and negative (Optional: Enable control wire)
Shell Material Aluminum With polish processing
RF output connector SMA-K
Dimension 112*37*16 mm Or Customize
Screw Size M2.5
Weight 230g Customize
WIDEBAND RFPA MODULES
Model Class Frequency Power Size
WB-10 100 MHz–3 GHz 10W 80 × 42 × 18 mm
WB-8 100 MHz–7 GHz 8W 150 × 80 × 23 mm
WB-10 400 MHz–6 GHz 10W 120 × 75 × 18 mm
WB-20 700 MHz–6 GHz 20W 200 × 100 × 23 mm
WB-30 700 MHz–6 GHz 30W 200 × 100 × 23 mm
WB-50 700 MHz–6 GHz 50W 200 × 100 × 23 mm
WB-80 1–6 GHz 80W 200 × 100 × 23 mm
WB-100 2–6 GHz 100W 150 × 80 × 23 mm
WB-100 1–3 GHz 100W 150 × 80 × 23 mm
WB-100 100 MHz–1 GHz 100W 200 × 100 × 23 mm
WB-100 300 MHz–2 GHz 100W 150 × 80 × 23 mm
WB-80 300 MHz–3 GHz 80W 158 × 122 × 25 mm
  • Wideband: 100 MHz–8 GHz
  • Output Power: 8 W–100 W
  • Compact & High Power Density
  • 28 V DC
  • OEM / Custom Solutions Available
