36W Medical Wall-Plug AC/DC Adapter: Multi-Voltage Ultra-Safe Power Solution

Product Overview

The 36W Medical Wall-Plug AC/DC Adapter is a high-capacity, clinical-grade power solution engineered for the rigorous safety and performance demands of diverse healthcare applications. Offering a wide range of output configurations, including 12V 3A and 24V 1.5A, this adapter is the premier power source for CPAP Machines, Infusion Pumps, and High-Resolution Patient Monitors.

Built to the highest global medical safety benchmarks, including full compliance with IEC 60601-1 (3.1 Edition), this unit features 2 x MOPP (Means of Patient Protection). It provides double-layered reinforced insulation and an ultra-low leakage current design, ensuring absolute safety for patients during prolonged therapy or monitoring. Its compact, wall-plug form factor is optimized for both clinical settings and home-care environments, providing a secure, interference-free link between the power grid and sensitive medical electronics.

Key Specifications

Our 36W medical series maximizes patient protection while offering flexible voltage options for various device requirements.

• Input Voltage: 100-240V AC, 50/60Hz (Universal Global Compliance).

• Total Output Power: 36W Continuous Maximum.

• Standard Output Options (Customizable):

  • 24V Series: 24V 1.5A (Optimized for motorized pumps and clinical actuators).

  • 12V Series: 12V 3A (Ideal for CPAP blowers and diagnostic displays).

  • Other Available Outputs: 5V 5A, 9V 4A, 15V 2.4A, 18V 2A.

• Medical Safety Compliance: Fully compliant with IEC/EN/ANSI/AAMI ES 60601-1 (3.1 Edition).

• Home Healthcare Standard: Certified to IEC 60601-1-11 (Safety for home-use medical equipment).

• Isolation Protection: 2 x MOPP (Means of Patient Protection) for superior electrical isolation.

• Leakage Current: Ultra-low leakage current (< 100µA) for maximum patient safety.

• Plug Types: Available in US/EU/UK/AU fixed or interchangeable wall plugs.

• Efficiency: Meets DoE Level VI and CoC Tier 2 energy efficiency standards.

• MTBF (Reliability): > 100,000 Hours, ensuring multi-year clinical uptime.

• Global Certifications: UL/cUL (Medical), CE (MDR), TUV-GS, CB, FCC, RoHS, REACH.

Ideal Applications

The 36W medical-grade output is optimized for high-performance healthcare and diagnostic electronics:

• Respiratory Care: CPAP/BiPAP machines, smart nebulizers, and portable ventilators.

• Infusion Systems: Volumetric infusion pumps, micro-syringe pumps, and enteral feeding controllers.

• Monitoring Devices: Multi-parameter patient monitors and bedside telemetry stations.

• Rehabilitation: High-power TENS Therapy Units and clinical Rehabilitation Devices.

• Diagnostic Tools: Mobile ultrasound displays and portable blood chemistry analyzers.

Professional Safety Suite

• Reinforced 2 x MOPP Isolation: 4000VAC primary-to-secondary isolation for absolute safety during invasive or non-invasive clinical procedures.

• Precision Motor Drive: Specialized filtering to ensure Low Ripple & Noise, preventing electronic artifacts from affecting the micro-controllers that govern flow rate or blower accuracy.

• Home-Healthcare Ready: Compliant with IEC 60601-1-11, specifically designed for medical equipment used in home environments.

• Anti-Bacterial & Flame-Retardant Casing: UL94 V-0 rated high-impact housing, designed to withstand frequent disinfection with clinical-grade chemical agents.

• Comprehensive Protection: Active Over-Voltage (OVP), Over-Current (OCP), and Short-Circuit Protection (SCP) with intelligent auto-recovery.
