15W Isolated Medical Power Unit: 9V 1.67A / 5V 3A High-Efficiency Solution

Product Overview

The 15W Isolated Medical Power Unit is a state-of-the-art, clinical-grade adapter specifically engineered for devices where signal integrity and patient safety are paramount. Delivering a stable 9V 1.67A or high-current 5V 3A output, this unit combines advanced synchronous rectification for High Efficiency with specialized filtering for Ultra-Low Ripple.

Built to the highest global medical safety benchmarks, including full compliance with IEC 60601-1 (3.1 Edition), this unit features 2 x MOPP (Means of Patient Protection). Its reinforced isolation barrier and ultra-low leakage current design provide an essential safety shield for patients and clinicians during high-precision monitoring. Its compact wall-plug form factor is optimized for modern clinical environments, ensuring a secure, interference-free power link for sensitive diagnostic electronics.

Key Specifications

Our 15W isolated series maximizes patient protection while ensuring peak performance for high-sensitivity physiological sensors and digital processors.

• Input Voltage: 100-240V AC, 50/60Hz (Universal Global Compliance).

• Total Output Power: 15W Continuous Maximum.

• Standard Output Options:

  • 9V 1.67A (Optimized for handheld diagnostic tools and testers).

  • 5V 3A (Ideal for high-current logic boards and USB-powered displays).

• Other Available Outputs:

  • 12V 1.25A

  • 15V 1A

  • 18V 0.83A

  • 24V 0.62A

• Medical Safety Compliance: Fully compliant with IEC/EN/ANSI/AAMI ES 60601-1 (3.1 Edition).

• Isolation Protection: 2 x MOPP (Means of Patient Protection) for superior electrical isolation.

• Leakage Current: Ultra-low leakage current (< 100µA) to ensure patient safety.

• Efficiency: Meets DoE Level VI and CoC Tier 2 high-efficiency energy standards.

• Plug Types: Available in US/EU/UK/AU fixed or interchangeable wall plugs.

• MTBF (Reliability): > 100,000 Hours, ensuring multi-year clinical uptime.

• Global Certifications: UL/cUL (Medical), CE (MDR), TUV-GS, CB, FCC, RoHS, REACH.

Ideal Applications

The 15W medical-grade output is optimized for high-sensitivity monitoring and therapeutic electronics:

• Diagnostic Monitoring: Portable ECG recorders, handheld capnography units, and digital pulse oximeters.

• High-Precision Sensors: Blood glucose meters, electronic stethoscopes, and fetal heart rate monitors.

• Therapy Equipment: Mid-power TENS Therapy Units and clinical Therapy Units.

• Rehabilitation: Advanced motorized Rehabilitation Devices and portable massage controllers.

• Remote Healthcare: Automated health tracking stations and remote patient monitoring (RPM) gateways.

Professional Safety Suite

• Reinforced 2 x MOPP Isolation: 4000VAC primary-to-secondary isolation for absolute safety during clinical procedures.

• Ultra-Low Ripple & Noise: Specialized output stage filtering to protect the integrity of micro-volt physiological signals from electrical interference.

• Green Power Technology: High-efficiency architecture reduces heat generation, extending the lifespan of both the adapter and the connected medical device.

• Anti-Bacterial & Flame-Retardant Casing: UL94 V-0 rated high-impact housing, designed to withstand frequent disinfection with clinical-grade chemical agents.

• Comprehensive Protection: Active Over-Voltage (OVP), Over-Current (OCP), and Short-Circuit Protection (SCP) with intelligent auto-recovery.
