Specifications
Place of Origin :
Guangdong, China
Brand Name :
cnlinko
Model Number :
YU-USB3-CPI-01-100
Certification :
UL,CE,ROHS,CCC,ISO9001
MOQ :
2
Price :
$7.13-14.26
Type :
usb
Application :
Data
Gender :
male and female, Female +male
Protection level :
IP67
Product type :
High Speed Usb Cable connector
Pin :
9pin
Current rating(A) :
1.5A
Shell & Insulated Parts :
High Performance Engineer Plastic
Hardware Matel :
Zinc Alloy (pearl hard chromium)
Connecting mode :
Quickly bayonet connect
Operating voltage :
500V
Description

CNLINKO USB 3.0 High Speed Data USB Cable Connector IP67 waterproof Circular usb port plug

Product Description

CNLINKO USB 3.0 High Speed Data USB Cable Connector IP68 Waterproof Circular USB Port Plug ConnectorCNLINKO USB 3.0 High Speed Data USB Cable Connector IP68 Waterproof Circular USB Port Plug ConnectorCNLINKO USB 3.0 High Speed Data USB Cable Connector IP68 Waterproof Circular USB Port Plug ConnectorCNLINKO USB 3.0 High Speed Data USB Cable Connector IP68 Waterproof Circular USB Port Plug ConnectorCNLINKO USB 3.0 High Speed Data USB Cable Connector IP68 Waterproof Circular USB Port Plug ConnectorCNLINKO USB 3.0 High Speed Data USB Cable Connector IP68 Waterproof Circular USB Port Plug Connector

Specifications
Specifications
Connecting mode Latching Lock connect
Protection level IP65/IP67
Cable specification 0.15mm2 ~ 0.2mm2 /26~24AWG
Diameter range Φ5.5mm ~Φ6.5mm
Contact diameter×Qty 9
Current rating(A) 1.5A
Temperature rise /
Withstanding voltage(AC.V)1min 1000V
Contact resistance <30mΩ
Insulation resistance >500MΩ
Durability ≥500 mating&unmating cycles
Temperature rating -40°C~80°C
Method of connecting cable Soldering
Prevent the combustion level UL94-V0
Material
Insulated parts High performance engineering plastics
Hardware metal Zinc alloy(pearl hard chromium)
Contact pin Copper alloy(gold-plated 4U)
Spring Stainless steel
Sealing Silica gel
Main characteristics
Sealed against dust and fluid (IP65/IP67)
Vibration resistance,impact resistance,stretching resistance
socket with cover
Application industries
Stage equipment - The smart grid
Medical equipment - Server
Solar energy equipment - Ship equipment
Electric power equipment - Vehicle equipment
Communications equipment - Heavy machinery

Certifications

CNLINKO USB 3.0 High Speed Data USB Cable Connector IP68 Waterproof Circular USB Port Plug Connector
