Specifications
Place of Origin :
Guangdong, China
Brand Name :
CNLINKO
Model Number :
BD-20-C02PE-02-001A&BD-20-J02SX-02-401A
Certification :
CUL,UL,CE,ROHS,CCC,ISO9001
MOQ :
10
Price :
$6-7
Type :
XLR
Application :
Power
Gender :
male and female
Produce type :
Power connector
Current rating(A) :
20A
Operating voltage :
300V
Protection level :
IP67/IP65
Shell Material :
PBT
Contact pin :
Copper alloy(gold-plated)
Assembly :
Solder
Description

Product Description

1.All-plastic/all-metal / two styles are optional, which can meet the differentiated demands of anti-interference, high strength and high corrosion resistance in different scenarios;
2.Adopt one key press button locking method, plug and play, fast and convenient;Precision waterproof design,

with high waterproof level, no fear of wading environment;
3.Adopt high-strength structural materials, pressure-resistant structure design, can withstand greater vibration and shock.

CNLINKO M20 2pin Waterproof IP68 Connector PBT Industrial Plug Socket Male Female Quick Electrical AC Power Adapter ConnectorsCNLINKO M20 2pin Waterproof IP68 Connector PBT Industrial Plug Socket Male Female Quick Electrical AC Power Adapter ConnectorsCNLINKO M20 2pin Waterproof IP68 Connector PBT Industrial Plug Socket Male Female Quick Electrical AC Power Adapter ConnectorsCNLINKO M20 2pin Waterproof IP68 Connector PBT Industrial Plug Socket Male Female Quick Electrical AC Power Adapter ConnectorsCNLINKO M20 2pin Waterproof IP68 Connector PBT Industrial Plug Socket Male Female Quick Electrical AC Power Adapter ConnectorsCNLINKO M20 2pin Waterproof IP68 Connector PBT Industrial Plug Socket Male Female Quick Electrical AC Power Adapter ConnectorsCNLINKO M20 2pin Waterproof IP68 Connector PBT Industrial Plug Socket Male Female Quick Electrical AC Power Adapter ConnectorsCNLINKO M20 2pin Waterproof IP68 Connector PBT Industrial Plug Socket Male Female Quick Electrical AC Power Adapter Connectors

Specifications
BD-20-C02PE-02-001A































































































































































































































































































































































































































































































































BD-20-J02SX-02-401A
Connecting mode Bayonet connection
Protection level IP67
Cable specification 4.0mm2 /12AWG
Diameter range Φ9mm ~Φ12mm
Contact diameter×Qty Φ2.7*2
Current rating(A) 20A
Operating voltage(AC.V.rms) 300V
Withstand voltage(AC.V)1min 2000V
Contact resistance <1.0mΩ
Insulation resistance >500MΩ
Durability ≥500 mating&unmating cycles
Temperature rating -40°C~85°C
Method of connecting cable Solder
Prevent the combustion level UL94-V0
Material
Shell&insulated parts High performance engineering plastics
Hardware metal Zinc alloy(pearl hard chromium)
Contact pin Copper alloy(gold-plated)
Spring Stainless steel
Sealing Silica gel
Main characteristics
Sealed against dust and fluid (IP65/IP67)
Vibration resistance,impact resistance,stretching resistance
bayonet connect; socket with cover
Application industries
Stage equipment - The smart grid
Medical equipment - Server
Solar energy equipment - Marine equipment
Electric power equipment - Vehicle equipment
Communications equipment - Heavy machinery
